Запчасти Komatsu PC600-6 BM ЦИЛИНДР ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ180

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XZ190

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

21M-63-02101

BOOM CYLINDER ASS'Y

1

21M-63-52141

CYLINDER

2

707-76-11160

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

07043-00108

PLUG

6

21M-63-52120

ROD

7

707-76-12530

BUSHING

8

07145-00125

SEAL,DUST (KIT)

9

707-71-32900

COLLAR

10

707-35-91840

RING,BACK-UP (KIT)

11

07000-15175

O-RING (KIT)

12

707-71-61320

PLUNGER

13

707-27-18960

HEAD

14

195-63-93170

SEAL,DUST (KIT)

15

07179-13136

RING,SNAP

16

707-52-90980

BUSHING

17

707-51-12030

PACKING,ROD (KIT)

18

707-51-12630

RING,BUFFER (KIT)

19

707-35-91840

RING,BACK-UP (KIT)

20

07000-15175

O-RING (KIT)

21

01011-82400

BOLT

22

707-88-75410

WASHER

23

707-36-18520

PISTON

24

01310-01225

SCREW

25

707-44-18280

RING,PISTON (KIT)

26

707-39-18830

RING,WEAR (KIT)

27

707-44-18920

RING

28

07001-05110

RING,BACK-UP (KIT)

29

07000-15110

O-RING (KIT)

30

21M-63-52171

TUBE,L.H.

30

21M-63-52271

TUBE,R.H.

31

21M-63-52180

TUBE,L.H.

31

21M-63-52280

TUBE,R.H.

32

01435-01055

BOLT

33

07000-13035

O-RING (KIT)

34

707-88-21170

BRACKET

35

707-88-95820

BAND

36

01010-81240

BOLT

37

01643-51232

WASHER

38

07283-23442

CLIP

39

01643-31032

WASHER

40

01599-01011

NUT

41

01010-81025

BOLT

42

01643-31032

WASHER

43

707-88-33040

CAP

44

07371-31049

FLANGE,SPLIT

45

07372-21035

BOLT

46

01643-51032

WASHER

|$55

707-99-68580

SERVICE KIT
