Запчасти Komatsu PC600-6 ОХЛАЖД-Е (РАДИАТОР И МАСЛООХЛАДИТЕЛЬ) (ДЛЯ ЕС)(№-999) СИСТЕМА ОХЛАЖДЕНИЯ

1

21M-03-18110

RADIATOR CORE ASS'Y

2

208-03-58370

CAP

3

205-03-62660

PLUG

4

07000-11007

O-RING

4

07000-01007

O-RING

5

20X-03-21170

HOSE

6

206-03-43340

CLIP

7

01010-81230

BOLT

8

01643-31232

WASHER

9

21M-03-18120

OIL COOLER ASS'Y

10

01010-81230

BOLT

11

01643-31232

WASHER

12

01010-81230

BOLT

13

01643-31232

WASHER

14

208-03-61250

SHEET

15

21M-03-11331

SEAL

16

21M-03-18210

SEAL

17

21M-03-18130

FRAME

18

21M-03-18140

FRAME

19

21M-03-18150

COVER

20

01010-81220

BOLT

21

01643-31232

WASHER

22

01010-81230

BOLT

23

01643-31232

WASHER

24

21M-03-11320

SEAL

25

21M-03-18220

SEAL

26

21M-03-18160

BRACKET

27

01010-81230

BOLT

28

01643-31232

WASHER

29

21M-03-18230

SEAL

30

21M-03-11490

SEAL

31

21M-03-18240

SEAL

32

21M-03-18290

SEAL

33

21M-03-11650

SEAL

34

21M-03-11660

SEAL

35

21M-03-11421

NET

36

21M-03-11411

NET

37

01434-10616

BOLT, WING

38

01643-30623

WASHER

39

21M-03-11150

SHROUD

40

21M-979-1810

BRACKET

41

01010-81025

BOLT

42

01643-31032

WASHER

43

21M-979-1820

BRACKET

44

01010-81025

BOLT

45

01643-31032

WASHER

46

208-979-6190

BRACKET

47

01010-81025

BOLT

48

01643-31032

WASHER
