Запчасти Komatsu PC60-8 ОСНОВН. КЛАПАН (-КЛАПАН) (/) Y [ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ]

|$1

723-27-50900

CONTROL VALVE

|$2

THIS ASSEMBLY CONSISTS OF ALLPARTS SHOWN IN FIGS.Y1662-01A0 TO Y1662-18A0

|$3

Ўо

BODY GROUP

1

Ўо

SPOOL

2

Ўо

PLUG

3

Ўо

ORIFICE

4

Ўо

RING

5

Ўо

O-RING

6

723-26-14650

SPRING

7

723-26-16940

FLANGE

8

722-12-19120

O-RING

9

01252-60640

BOLT

10

Ўо

ORIFICE

11

722-12-15160

RING

12

07002-10823

O-RING

13

723-26-16350

FLANGE

14

723-11-19110

O-RING

15

723-26-16360

SLEEVE

16

723-26-16371

PISTON

17

723-26-16380

SPRING

18

01252-60820

BOLT

19

723-26-16390

CASE

20

723-11-19110

O-RING

21

Ўо

SLEEVE

22

723-26-16420

RETAINER

23

Ўо

PISTON

24

Ўо

VALVE

25

723-26-16450

SPRING

26

01252-60855

BOLT

27

708-8E-16160

PLUG

28

07002-11023

O-RING

29

Ўо

PLUG

30

723-26-16460

PLUG

31

07000-11007

O-RING

32

07001-01007

RING, BACK-UP

33

07000-12120

O-RING

34

07000-12020

O-RING

35

723-26-15840

O-RING

36

07000-11008

O-RING

37

07000-11006

O-RING
