Запчасти Komatsu PC60-8 ЦИЛИНДР КОВША Y [ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ]

|$1

??707-G0-X1350

CYLINDER GROUP, BUCKET

|$2

??707-E0-X1350

CYLINDER GROUP

|$3

707-00-0J901

CYLINDER ASS'Y, BUCKET

1

707-11-90A20

CYLINDER, BUCKET

2

07143-10505

BUSHING

3

07145-00050

SEAL, DUST (KIT)

4

707-29-90A20

HEAD

5

707-52-90301

BUSHING

6

707-51-55860

PACKING, ROD (KIT)

7

707-56-55740

SEAL, DUST (KIT)

8

07179-12069

RING, SNAP

9

07000-B2085

O-RING (KIT)

10

07146-02086

RING, BACK-UP (KIT)

11

07000-B2090

O-RING (KIT)

12

721-58-55700

ROD, PISTON

13

07144-10606

BUSHING

14

07145-00060

SEAL, DUST (KIT)

15

07020-00000

FITTING, GREASE

16

707-36-90862

PISTON

17

707-44-90150

RING, PISTON (KIT)

18

07156-00912

RING, WEAR (KIT)

19

707-67-42020

NUT

20

707-86-48860

TUBE

21

707-86-48870

TUBE

22

01010-81020

BOLT

23

01643-31032

WASHER

24

02896-61012

O-RING (KIT)

25

707-51-55650

RING, BUFFER (KIT)

26

707-45-90940

WASHER, LOCK

27

707-44-90930

RING

28

707-40-90420

RETAINER

|$32

SERVICE KIT

|$33

707-99-26710

SERVICE KIT, BUCKET CYLINDER

36

20B-27-11210

BLEEDER
