Запчасти Komatsu PC60-7S ОСНОВНАЯ РАМА (ТЕЛЕСКОПИЧЕСК. РУКОЯТЬ) ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

1

FRAME,REVOLVING

|1

FRAME,REVOLVING

|1

FRAME,REVOLVING

|1

FRAME,REVOLVING

|1

FRAME,REVOLVING

|1

FRAME,REVOLVING (FOR SIDE BUMPER)

|1

FRAME,REVOLVING (FOR SIDE BUMPER)

|1

FRAME,REVOLVING (FOR SIDE BUMPER)

1A

201-46-73250

SHEET

2

203-46-56160

COVER

3

203-46-31181

GASKET

|3

203-46-31181

GASKET

4

01010-81230

BOLT

5

01643-31232

WASHER

6

201-46-71170

PLATE

7

01010-81225

BOLT

|7

01010-81230

BOLT

8

01643-31232

WASHER

9

201-46-71220

SHEET

10

201-46-73190

SPACER¤ 12MM

11

201-46-73240

PLATE

12

01010-81025

BOLT

13

01643-31032

WASHER

14

201-70-77610

TUBE

15

08036-01014

CLIP

16

01010-81020

BOLT

17

01643-31032

WASHER

18

201-70-75451

BRACKET

19

01010-81020

BOLT

20

01643-31032

WASHER

21

07214-51013

CONNECTOR

22

07221-20210

NUT

23

07222-00210

PLUG

24

07042-20211

PLUG
