Запчасти Komatsu PC60-7E-B ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-00-XA050

CYLINDER GROUP,(NATURAL YELLOW)

|G1

707-00-XA060

CYLINDER GROUP,(VIOLET BLUE)

|G1

201-63-X2511

CYLINDER GROUP

|1

707-00-0A050

CYLINDER ASS'Y,ARM

|1

201-63-02511

CYLINDER ASS'Y \,ARM

1

201-63-64741

CYLINDER,ARM

2

07143-10506

BUSHING

3

07145-00055

SEAL,DUST (KIT)

4

707-29-10341

HEAD,CYLINDER

|4

707-29-10280

HEAD,CYLINDER

5

07177-06030

BUSHING

6

707-51-60211

PACKING,ROD (KIT)

7

141-63-93270

SEAL,DUST (KIT)

8

07179-12074

RING,SNAP

9

07000-12095

O-RING (KIT)

10

707-35-91050

RING,BACK-UP (KIT)

11

07000-12100

O-RING (KIT)

12

07000-12095

O-RING (KIT)

13

07146-02096

RING,BACK-UP (KIT)

14

201-63-64720

ROD,PISTON

15

07143-10606

BUSHING

16

07145-00060

SEAL,DUST (KIT)

17

707-71-70690

PLUNGER

18

707-36-10420

PISTON

19

707-44-10180

RING,PISTON (KIT)

20

07156-01012

RING,WEAR (KIT)

21

707-71-60100

PLUNGER

22

04260-00635

BALL

23

707-71-91280

CAP

24

07165-14244

NUT

25

113-63-22390

ELBOW

26

07002-12034

O-RING (KIT)

27

201-63-64770

TUBE

28

07283-22236

CLIP

29

01599-01011

NUT

30

01643-31032

WASHER

K

707-98-35181

SERVICE KIT,ARM CYLINDER
