Запчасти Komatsu PC60-7 МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC60-7 - МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
2
2A
2A
2B
2B
2C
2C
2D
2D
3
4
5
6
6
7
8
9
10
11
12
13
13
14
15
16
16
17
18
19
20
21
22
23
24
24
24
25
25
26
27
28
29

Артикул

Название

Примечание

Количество

|$3

708-7T-00470

MOTOR ASS'Y

|$4

708-7T-00360

MOTOR ASS'Y

|$5

708-7T-00240

MOTOR ASS'Y

|$10

708-7T-01210

MOTOR SUB ASS'Y

|$11

708-7T-01040

MOTOR SUB ASS'Y

1

708-7T-11240

CASE,MOTOR

2

708-7T-11670

COVER,END

2

708-7T-11640

COVER,END

2A

706-73-72420

VALVE

2B

706-73-72440

SPRING

2C

706-73-72430

PLUG

2D

07002-12434

O-RING

3

708-7T-51210

O-RING

4

720-68-19610

PIN

5

01010-81250

BOLT

6

708-7T-12420

SHAFT

6

708-7T-12220

SHAFT

7

708-7T-12240

BEARING

8

708-7T-12250

BEARING

9

708-7T-05020

SPACER KIT

9

SPACER, 1.6MM

9

SPACER, 1.7MM

9

SPACER, 1.8MM

9

SPACER, 1.9MM

9

SPACER, 2.0MM

9

SPACER, 2.1MM

9

SPACER, 2.2MM

10

708-7T-12230

SEAL,OIL

11

04065-04518

RING,SNAP

12

708-7T-13140

BLOCK,CYLINDER

13

708-7T-13290

PLATE,VALVE

13

708-7T-13261

PLATE,VALVE

14

720-68-19610

PIN

15

708-7T-13540

PIN

16

708-7T-13530

WASHER

17

708-7T-13570

SPRING

18

04065-03815

RING

19

708-7T-13510

GUIDE,RETAINER

20

708-7T-13342

RETAINER,SHOE

21

708-7T-13352

PISTON SUB ASS'Y

21

708-7T-13611

PISTON SUB ASS'Y

22

708-7T-53420

PLATE,THRUST

22

708-7T-13421

PLATE,THRUST

23

708-7T-13710

SPACER

24

708-7T-52512

PLATE

25

708-7T-15120

DISC

26

708-7T-15140

PISTON,BRAKE

27

07000-12130

O-RING

28

708-7T-55220

O-RING

29

708-7T-15150

SPRING

Выбрано товаров: 50
