Запчасти Komatsu PC60-7 ОСНОВН. КОНСТРУКЦИЯ (P.P.C. РАБОЧАЯ ЛИНИЯ)(№7-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
№
Артикул
Название
Примечание
Количество
|$103
201-62-73600
HOSE ASS'Y
|$104
201-62-78420
HOSE ASS'Y
|$105
201-62-74330
HOSE ASS'Y
1
201-62-73661
HOSE, 1655MM
1
201-62-73660
HOSE, 1605MM
1
20Y-62-23431
HOSE, 1600MM
1
201-62-74410
HOSE, 1600MM
1
20U-62-22190
O-RING
1
21U-62-34710
BAND, YELLOW
2
21W-62-31450
HOSE, 1600MM
2
201-62-74430
HOSE, 1600MM
2
21U-62-34760
BAND, RED
3
21W-62-31450
HOSE, 1600MM
3
21W-62-32210
HOSE, 1500MM
3
201-62-74640
HOSE, 1500MM
3
21U-62-34750
BAND, BLUE
4
201-62-72560
HOSE, 1700MM
4
201-62-74440
HOSE, 1700MM
4
21U-62-34750
BAND, BLUE
4
21U-62-34770
BAND, WHITE
5
201-62-78330
HOSE, 1400MM
5
201-62-74450
HOSE, 1400MM
5
21U-62-34760
BAND, RED
5
21U-62-34730
BAND, GREEN
6
21W-62-31450
HOSE, 1600MM
6
21W-62-32210
HOSE, 1500MM
6
201-62-74640
HOSE, 1500MM
6
21U-62-34720
BAND, BLACK
6A
08034-00823
BAND
7
20Y-62-16170
BOLT
8
07000-12015
O-RING
9
702-16-53240
PLUG
10
07000-12018
O-RING
11
07230-20210
UNION
11
21A-62-12360
NIPPLE
12
07002-11423
O-RING
13
07236-10210
ELBOW
13
21U-62-24160
ELBOW
14
07002-11423
O-RING
|$144
201-62-73500
HOSE ASS'Y
|$145
201-62-78410
HOSE ASS'Y
|$146
201-62-74320
HOSE ASS'Y
15
201-62-78360
HOSE, 1600MM
15
201-62-74390
HOSE, 1600MM
15
21U-62-34760
BAND, RED
15
21U-62-34730
BAND, GREEN
16
201-62-73650
HOSE, 1505MM
16
201-62-78340
HOSE, 1500MM
16
20T-62-83570
HOSE, 1500MM
16
21U-62-34780
BAND, BROWN
17
201-62-73950
HOSE, 1555MM
17
201-62-73650
HOSE, 1505MM
17
201-62-78340
HOSE, 1500MM
17
20T-62-83570
HOSE, 1500MM
17
21U-62-34770
BAND, WHITE
18
201-62-73650
HOSE, 1505MM
18
201-62-78340
HOSE, 1500MM
18
20T-62-83570
HOSE, 1500MM
18
21U-62-34740
BAND, ORANGE
19
201-62-73640
HOSE, 1405MM
19
20Y-62-25521
HOSE, 1400MM
19
201-62-74360
HOSE, 1400MM
19
21U-62-34730
BAND, GREEN
20
201-62-78350
HOSE, 1400MM
20
201-62-74380
HOSE, 1400MM
20
21U-62-34750
BAND, BLUE
20
21U-62-34770
BAND, WHITE
21
20Y-62-16170
BOLT
22
07000-12015
O-RING
23
702-16-53240
PLUG
24
07000-12018
O-RING
25
07230-20210
UNION
25
21A-62-12360
NIPPLE
26
07002-11423
O-RING
27
07236-10210
ELBOW
27
21U-62-24160
ELBOW
28
07002-11423
O-RING
29
201-62-72570
CLAMP
30
01010-81016
BOLT
31
01643-31032
WASHER
32
04434-53211
CLIP
32
04434-52711
CLIP
33
01010-81016
BOLT
34
01643-31032
WASHER
Выбрано товаров: 84
