Запчасти Komatsu PC60-7 ХОД MTOR (/)(№878-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC60-7 - ХОД MTOR (/)(№878-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
7
8
8
9
9
10
11
12
13
14
15
16
17
18
19
19
20
21
21
22
23
24
25
26
27
27
28
29

Артикул

Название

Примечание

Количество

|1

201-60-73500

TRAVEL MOTOR ASS'Y

|1

TZ502D1000-00

FINAL ASS'Y

|1

TZ500D1102-00

SPINDLE KIT

|1

TZ500D1132-00

SPINDLE ASS'Y

1

SPINDLE

2

FLANGE,HOLD

3

TZ500D1019-00

BOLT,REAMER

|4

TZ500D1104-00

RV GEAR ASS'Y

|4

TZ500D1204-00

RV GEAR KIT

4

RV GEAR

5

RV GEAR

6

SHAFT,CRANK

7

SPACER

8

BEARING

9

BEARING

|10

TZ502D1107-00

SPUR GEAR KIT (3 PIECES)

10

SPUR GEAR

|11

TZES20423232-B

FLOATING SEAL ASS'Y (KIT)

11

SEAL,FLOATING (KIT)

12

TZ500D1001-00

HUB

13

TZ502D1006-00

GEAR,INPUT

14

TZ500D1008-00

COVER

15

TZ500D1015-00

SHAFT

16

TZ500D1017-00

PIN

17

TZ810B1018-00

RING

18

TZ860A1013-00

SNAP RING SET (15 KINDS)

19

TZ500D1021-00

BEARING

20

TZJB2804-S19

RING,SNAP

21

04064-02512

RING,SNAP

22

07000-11008

O-RING (KIT)

23

07000-15230

O-RING (KIT)

24

TZJW1516-G35-5

O-RING (KIT)

25

TZ410D1033-00

PLUG

26

TZ810B2021-00

PLUG

27

07000-12014

O-RING (KIT)

28

04260-00952

BALL

29

TZJB1354-8-22

PIN

K

TZ505D9000-00

SEAL KIT

Выбрано товаров: 38
