Запчасти Komatsu PC60-7 МОТОР ХОДА (/)(№878-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

201-60-73500

TRAVEL MOTOR ASS'Y

|1

TZ500D200000-G

MOTOR ASS'Y

|1

TZ500D2105-00

PISTON KIT

1

PISTON ASS'Y

2

TZ500D2070-00

PISTON ASS'Y

3

TZ500D2002-00

SHAFT

4

TZ500D200300-G

PLATE,SWASH

5

TZ500D2004-00

BLOCK,CYLINDER

6

TZ500D2007-00

PLATE,RETAINER

7

TZ500D2008-00

BOWL,THRUST

8

TZ500D2009-00

PLATE,TIMING

9

TZ500D2010-00

WASHER

10

TZ500D2012-00

PISTON

11

TZ500D2013-00

SPRING

12

TZ500D2014-00

SPRING

13

TZ500D2015-00

DISC

14

TZ500D2016-00

PLATE

15

TZ15Z-22-42-10

SEAL,OIL (KIT)

16

TZ500D2035-00

O-RING (KIT)

17

TZ500D2039-00

O-RING (KIT)

18

TZIRTW-36

RING,SNAP

19

TZ880A2029-00

BEARING

20

06000-06301

BEARING

21

TZ500D2098-00

PIN

22

TZ500D2076-00

PIVOT

23

TZ263B2077-01

PIN

24

TZ844B2085-00

SPRING

K

TZ505D9000-00

SEAL KIT,TRAVEL MOTOR
