Артикул
Название
Примечание
Количество
|1
201-70-00930
BOOM ASS'Y
|1
201-70-00910
BOOM ASS'Y
|1
201-70-00610
BOOM ASS'Y
1
BOOM
|1
BOOM
|1
BOOM
|2
201-70-71XE1
BRACKET (WELDED)
|2
201-70-71XA0
BRACKET (WELDED)
2
BRACKET (WELDED)
|2
BRACKET (WELDED)
3
203-46-41130
SEAT (WELDED)
4
201-70-71230
BUSHING
5
07145-00065
SEAL,DUST
6
07145-00065
SEAL,DUST
7
201-06-71280
WORK LAMP ASS'Y,70W
8
203-06-56410
BRACKET
9
01010-51225
BOLT
10
01643-31232
WASHER
11
201-06-61360
WIRE
12
203-06-56570
BAND
13
201-70-71610
PIN,.
|13
201-70-71261
PIN,.
14
203-46-56270
PLATE
15
01010-51230
BOLT
16
01643-31232
WASHER
17
203-70-24150
SPACER¤ 1.0MM
18
201-70-71270
SHAFT
19
203-46-56270
PLATE
20
01010-51230
BOLT
21
01643-31232
WASHER
22
202-70-11640
SPACER¤ 1.0MM
|22
203-70-34260
SPACER¤ 0.5MM
23
201-70-71250
PIN
24
04082-00212
LOCK
25
01010-51230
BOLT
26
01643-31232
WASHER
27
201-70-71280
SPACER¤ 1.0MM
28
201-62-71420
HOSE
|28
201-62-71420
HOSE
28A
201-62-77110
HOSE
29
201-62-74110
TUBE
30
201-62-74121
TUBE
|30
201-62-74120
TUBE
31
201-62-74130
TUBE
32
201-62-74140
TUBE
33
203-70-53380
CLAMP
|33
203-70-53380
CLAMP
33A
201-973-7430
CLAMP
34
203-70-53390
CLAMP
35
201-63-X2302
CYLINDER GROUP,BOOM (SEE FIG.Y1620-01A0)
36
201-63-X2313
CYLINDER GROUP,ARM (SEE FIG.Y1620-11A0)
|36
201-63-X2312
CYLINDER GROUP,ARM (SEE FIG.Y1620-11A0)
Выбрано товаров: 52
