Запчасти Komatsu PC60-7 СТРЕЛА (ДЛЯ CHINA)(№99-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$2

201-70-00681

BOOM ASS'Y

1

BOOM

|$6

201-70-71XE1

BRACKET (WELDED)

2

BRACKET (WELDED)

3

203-46-41130

SEAT (WELDED)

4

21W-70-41610

BUSHING

5

07145-00065

SEAL,DUST

6

07145-00065

SEAL,DUST

7

201-06-71280

WORK LAMP ASS'Y

7

421-06-23330

BULB, 70W

8

203-06-56410

BRACKET

9

01010-81225

BOLT

10

01643-31232

WASHER

11

201-06-71360

WIRING HARNESS

12

203-06-56570

BAND

12A

04434-50608

CLIP

12B

01010-80816

BOLT

12C

01643-30823

WASHER

13

201-70-71610

PIN

14

203-46-56270

PLATE

15

01010-81230

BOLT

16

01643-31232

WASHER

17

21Y-70-14770

SPACER, 1.0MM

18

201-70-71270

SHAFT

19

203-46-56270

PLATE

20

01010-81230

BOLT

21

01643-31232

WASHER

22

21W-70-32280

SPACER, 1.0MM

22

20U-70-31310

SPACER, 0.5MM

23

201-70-71250

PIN

24

04082-00212

LOCK

25

01010-81230

BOLT

26

01643-31232

WASHER

27

201-70-71380

SPACER, 1.0MM

28

201-62-71420

HOSE

29

201-62-77110

HOSE

30

201-62-74110

TUBE

31

201-70-77720

TUBE

32

201-62-74130

TUBE

33

201-62-74140

TUBE

34

203-70-53380

CLAMP

35

203-70-53390

CLAMP

36

01010-81025

BOLT

37

01643-31032

WASHER
