Запчасти Komatsu PC58UU-3 ЛИНИЯ АКТУАТОРА (ДЛЯ ПОДЪЕМА РУКОЯТИ) ГИДРАВЛИКА

1

20U-62-42840

HOSE¤ 740MM,BLACK-RED

2

02765-00407

HOSE¤ 700MM,ORANGE-YELLOW

3

20U-62-42830

HOSE¤ 640MM,BROWN-YELLOW

4

20U-62-42850

HOSE¤ 880MM,GREEN YELLOW

5

02760-003A8

HOSE¤ 850MM

6

02760-00309

HOSE¤ 900MM,RED-YELLOW

7

02760-00309

HOSE¤ 900MM,BROWN

8

20U-62-42870

HOSE¤ 840MM,BLUE-YELLOW

9

20U-62-42880

HOSE¤ 1170MM,WHITE

10

07095-20420

CUSHION

11

08034-20834

BAND

12

20U-62-43610

HOSE¤ 1560MM,ORANGE

13

20U-62-43610

HOSE¤ 1560MM,GREEN

14

20U-62-43610

HOSE¤ 1560MM,BLUE

15

20U-62-43610

HOSE¤ 1560MM,RED

16

20U-62-43620

HOSE¤ 1550MM,RED-WHITE

17

20U-62-43620

HOSE¤ 1550MM,RED-WHTIE

18

02896-11012

O-RING

19

02896-11009

O-RING

20

02765-00403

HOSE,YELLOW

21

20U-62-42860

HOSE¤ 345MM,BLACK

22

20U-62-42910

HOSE

23

20U-62-42920

HOSE

24

20U-62-41560

BRACKET

25

02896-11012

O-RING

26

01010-81025

BOLT

27

01643-31032

WASHER

28

20U-62-41592

BRACKET

29

01010-81020

BOLT

30

01643-31032

WASHER

31

01010-81065

BOLT

32

01643-31032

WASHER

33

08034-20519

BAND
