Запчасти Komatsu PC58UU-3 МЕХАНИЗМ ПОВОРОТА (ВНУТР. ЧАСТИ) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|1

20U-26-00121

SWING MACHINERY A.

1

20T-26-81180

CARRIER

2

20T-26-81121

GEAR

3

20S-26-81260

PIN

4

20T-26-81430

BEARING

5

20S-26-71160

WASHER

6

20S-26-71190

RING

7

20S-26-71250

PIN

8

20T-26-81190

CARRIER

9

20T-26-81140

GEAR

10

20T-26-81250

PIN

11

20T-26-71190

BEARING

12

20T-26-81151

GEAR

13

20T-26-81231

SPACER

14

20U-26-32110

SHAFT

15

20T-26-71221

BEARING

16

20U-26-31150

BEARING

17

20T-26-81210

SEAL

18

20U-26-31160

CASE

19

01253-61210

BOLT

20

01252-61290

BOLT

21

01643-51232

WASHER

22

20T-26-81240

WASHER

23

20U-26-31140

SEAL

24

20T-26-81110

GEAR

25

20T-26-81130

GEAR

26

07049-01215

PLUG

27

04064-04018

RING,SNAP

28

04020-01434

PIN,DOWEL

29

708-7R-00340

MOTOR ASS'Y

30

20S-26-81310

RING

31

708-7T-51210

O-RING

32

02783-10315

ELBOW

33

02896-11009

O-RING

34

07002-12034

O-RING

35

21X-62-21140

ELBOW

36

02782-10315

ELBOW

37

02896-11009

O-RING

38

07002-12034

O-RING

39

02782-10210

ELBOW

40

02896-11008

O-RING

41

07002-11423

O-RING

42

02783-10210

ELBOW

43

02896-11008

O-RING

44

07002-11423

O-RING
