Запчасти Komatsu PC58UU-3 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-00-XA451

ARM CYLINDER GROUP,(VIOLET BLUE)

G1

707-02-X0110

ARM CYLINDER GROUP,(NATURAL YELLOW)

|$3

707-00-0A451

CYLINDER ASS'Y,ARM

1

707-12-90091

CYLINDER,ARM

2

707-76-55440

BUSHING

3

07145-00055

SEAL,DUST (KIT)

3A

02896-11012

O-RING (KIT)

4

707-29-90740

HEAD,CYLINDER

5

07177-05530

BUSHING

6

707-51-55211

PACKING,ROD (KIT)

7

707-56-55510

SEAL,DUST (KIT)

8

07179-12069

RING,SNAP

9

07000-12085

O-RING (KIT)

10

07146-02086

RING,BACK-UP (KIT)

11

07000-12090

O-RING (KIT)

12

721-58-55210

ROD,PISTON

13

20T-870-1290

BUSHING

14

07145-00050

SEAL,DUST (KIT)

15

07020-00000

FITTING,GREASE

16

707-36-90460

PISTON

17

707-44-90180

RING,PISTON (KIT)

18

07156-00912

RING,WEAR (KIT)

19

707-71-60050

PLUNGER

20

04260-00635

BALL

21

707-71-91290

PLUG

22

707-67-42010

NUT

23

707-86-46830

TUBE

24

707-86-46841

TUBE

25

02896-11012

O-RING (KIT)

26

01010-81025

BOLT

27

01643-31032

WASHER

K

707-98-26710

SERVICE KIT,ARM CYLINDER
