Запчасти Komatsu PC58SF-1 ОСНОВН. КОНСТРУКЦИЯ (ЭЛЕКТРИКА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20U-54-33271

BRACKET

|1

20U-54-33270

BRACKET

2

01010-81020

BOLT

3

01643-31032

WASHER

4

20T-06-71650

RELAY

5

01220-40612

SCREW

6

01602-20619

WASHER,SPRING

7

01641-20608

WASHER

8

08038-00519

CAP

9

01220-40612

SCREW

10

01643-30623

WASHER

11

01602-20619

WASHER,SPRING

12

21Y-06-11260

BUZZER ASS'Y

13

21Y-06-11270

PLATE

14

01220-40616

SCREW

15

01643-30623

WASHER

16

01602-20619

WASHER,SPRING

17

22B-06-11480

SWITCH

|17

20T-06-71770

SWITCH

17A

20U-43-21480

BRACKET

18

01010-80820

BOLT

|18

20U-43-21360

SCREW

19

01643-30823

WASHER

|19

01641-20508

WASHER

20

20T-06-71532

HARNESS

21

7824-63-1900

RESISTOR

|21

7827-11-1520

RESISTOR

22

01010-80816

BOLT

23

01643-30823

WASHER

24

20T-06-71750

RELAY ASS'Y

25

20T-06-71760

TIMER

26

01220-40616

SCREW

27

01643-30623

WASHER

28

01602-20619

WASHER,SPRING

29

21X-06-12310

RELAY ASS'Y

30

01220-40616

SCREW

31

01643-30623

WASHER

32

01602-20619

WASHER,SPRING
