Запчасти Komatsu PC58SF-1 РАДИАТОР И МАСЛООХЛАДИТЕЛЬ СИСТЕМА ОХЛАЖДЕНИЯ

1

20U-03-21261

CORE ASS'Y

2

20U-03-21240

SHROUD

3

01010-80814

BOLT

4

01643-30823

WASHER

5

205-03-62660

PLUG

6

07000-01007

O-RING

7

20U-03-21540

CAP

|7

104-03-41230

CAP

8

07270-00827

TUBE

9

20U-03-21212

COVER

10

20U-03-21221

COVER

11

01010-80814

BOLT

12

01643-30823

WASHER

13

20U-03-21230

SEAL

14

20T-03-71750

SEAL

15

08037-01610

GROMMET

16

20U-03-21460

SHEET

17

20U-03-21470

SEAL

18

20U-03-31110

OIL COOLER ASS'Y

|18

20U-03-21113

OIL COOLER ASS'Y

19

01010-80820

BOLT

20

01643-30823

WASHER

21

20U-03-21251

NET

22

01010-80814

BOLT

23

01643-30823

WASHER

24

08036-01214

CLIP

25

20U-03-21520

HOSE

26

07289-00045

CLAMP

|26

207-09-11110

CLAMP

27

20U-03-21531

HOSE

28

07289-00045

CLAMP

|28

207-09-11110

CLAMP

29

20T-03-71760

SHEET

30

20T-03-71160

PLATE

31

01010-81025

BOLT

32

01643-31032

WASHER

33

203-03-56330

CUSHION

34

01580-11008

NUT

35

01643-31032

WASHER

36

20U-03-21411

BRACKET

37

01010-81030

BOLT

38

01643-31032

WASHER

39

203-03-56330

CUSHION

40

01580-11008

NUT

41

01643-31032

WASHER

42

20U-03-21420

SHEET

43

20U-03-21441

SHEET
