Запчасти Komatsu PC58SF-1 ОСНОВН. КЛАПАН (КОРПУС) ГИДРАВЛИКА

1

20U-62-32610

BRACKET

2

203-62-42770

CUSHION

3

20X-62-21550

SPACER

4

07000-13025

O-RING

5

283-62-18110

WASHER

6

01010-81260

BOLT

7

01643-31232

WASHER

8

20U-43-31721

BRACKET

9

20U-43-31730

LEVER

10

20U-43-31740

SHAFT

11

01010-80830

BOLT

12

01602-20825

WASHER,SPRING

13

195-61-34120

BEARING

14

04010-00519

KEY

15

104-43-25190

YOKE

16

04205-10516

PIN

17

04052-10530

PIN,SPRING

18

20U-43-31750

YOKE

19

04205-10514

PIN

20

04052-10530

PIN,SPRING

21

01010-80820

BOLT

22

01643-30823

WASHER

23

20U-43-31711

BRACKET

24

01010-80820

BOLT

25

01010-80825

BOLT

26

01643-30823

WASHER

27

20U-43-31760

CABLE,BLADE CONTROL

28

20U-43-21330

PLATE

29

04434-51010

CLIP

30

01010-81020

BOLT

31

01643-31032

WASHER

32

20U-43-21181

CABLE,TRAVEL CONTROL

33

104-43-25190

YOKE

34

04205-10516

PIN

35

04052-10530

PIN,SPRING

36

20U-43-21330

PLATE
