Запчасти Komatsu PC58SF-1 ОСНОВН. КЛАПАН (/7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-19-11102

CONTROL VALVE

|1

723-19-11101

CONTROL VALVE

|1

723-19-11100

CONTROL VALVE

1

723-11-18170

VALVE

2

723-11-18180

SPRING

3

723-11-18190

PLUG

4

07002-11023

O-RING

5

PLUG

6

07001-01009

RING,BACK-UP

7

723-11-18520

SEAT

8

723-11-19960

O-RING

9

VALVE

10

723-11-18550

RETAINER

11

723-11-18540

SPRING

12

723-11-18120

PLUG

13

07001-01007

RING,BACK-UP

14

BLOCK

15

07000-12018

O-RING

16

01252-60620

BOLT

17

723-11-19760

PLATE

18

07000-12015

O-RING

19

07000-11007

O-RING

20

07000-11009

O-RING

21

04530-00815

BOLT,EYE

22

702-21-54260

O-RING

23

POPPET

24

SLEEVE

25

PISTON

26

SPOOL

27

723-11-19720

SPACER

28

723-11-19710

SPRING

29

723-11-19690

PLUG

30

07002-11423

O-RING

31

01252-60635

BOLT

32

01252-60630

BOLT

33

723-11-19770

BLOCK

34

702-21-53120

FILTER

35

702-21-55420

O-RING

36

702-21-55520

O-RING

37

723-11-18190

PLUG

38

07002-11023

O-RING
