Запчасти Komatsu PC58SF-1 МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-7R-00210

MOTOR ASS'Y

|1

708-7R-00160

MOTOR ASS'Y

|1

708-7R-01110

MOTOR SUB ASS'Y

1

708-7R-11611

PLATE,SWASH

2

708-7R-11710

WASHER

3

708-7R-11720

FILTER

|4

708-7R-04060

HOUSING SUB ASS'Y

4

HOUSING

5

PLUG

6

708-7R-11220

PLUG

7

07002-11223

O-RING

8

708-7R-11210

VALVE

9

708-7R-11280

SPRING

10

709-32-12861

PLUG

11

07002-11823

O-RING

|12

708-7R-03020

VALVE SUB ASS'Y

12

708-7R-11230

VALVE

13

708-7R-11240

POPPET

14

708-7R-11250

PLUG

15

722-10-91130

SPRING

16

708-7R-11270

PLUG

17

07002-11823

O-RING

18

431-40-11210

O-RING

19

720-68-19610

PIN

20

01252-61230

BOLT

21

708-7R-12120

SHAFT

22

708-7R-12140

BEARING

23

708-7R-12150

BEARING

24

04065-04218

RING

25

708-7R-13111

BLOCK,CYLINDER

26

708-7R-13220

PLATE,VALVE

27

720-68-19610

PIN

28

708-7R-13540

PIN

29

708-7R-13530

WASHER

30

708-7R-13560

SPRING

31

04065-03012

RING

32

708-7R-13510

GUIDE,RETAINER

33

708-7R-13351

RETAINER,SHOE

34

708-7R-13310

PISTON SUB ASS'Y

35

708-7R-13410

PLATE,THRUST

36

708-7R-13581

SPACER

37

708-7R-15130

PLATE

38

708-7R-15121

DISC

39

708-7R-15180

PISTON,BRAKE

40

07000-12115

O-RING

41

07000-12095

O-RING

42

708-7R-15150

SPRING

43

708-7R-15160

RING

44

708-7R-15712

PISTON

45

708-7R-15722

SPRING

|46

708-7R-03030

VALVE SUB ASS'Y

46

VALVE

47

FILTER

48

708-7R-15670

SPRING

49

706-73-72680

PLUG

50

07002-11223

O-RING

51

07235-10422

ELBOW

52

07002-12034

O-RING

53

07221-20422

NUT,SLEEVE

54

07222-00414

PLUG
