Запчасти Komatsu PC58SF-1 СТРЕЛА OFFSET ЦИЛИНДР (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

20U-63-X2231

OFFSET CYLINDER G.

|1

20U-63-02231

CYLINDER ASS'Y,OFFSET

1

20U-63-86340

CYLINDER,OFFSET

2

20T-870-1290

BUSHING

3

07145-00050

SEAL,DUST (KIT)

4

07020-00900

FITTING,GREASE

5

707-29-90730

HEAD,CYLINDER

6

07177-05030

BUSHING

7

707-51-50211

PACKING,ROD (KIT)

8

176-63-92240

SEAL,DUST (KIT)

9

07179-12062

RING,SNAP

10

07000-12085

O-RING (KIT)

11

07146-02086

RING,BACK-UP (KIT)

12

07000-02090

O-RING (KIT)

13

20U-63-86320

ROD,PISTON

14

20T-870-1290

BUSHING

15

07145-00050

SEAL,DUST (KIT)

16

07020-00900

FITTING,GREASE

17

707-36-90260

PISTON

18

707-44-90180

RING,PISTON (KIT)

19

07156-00912

RING,WEAR (KIT)

20

01580-03629

NUT

21

20U-63-86380

TUBE

22

01010-81020

BOLT

23

01643-31032

WASHER

K

707-98-25520

SERVICE KIT,OFFSET CYLINDER

|K

07145-00050

SEAL,DUST

|K

707-51-50211

PACKING,ROD

|K

176-63-92240

SEAL,DUST

|K

07000-12085

O-RING

|K

07146-02086

RING,BACK-UP

|K

07000-02090

O-RING

|K

07145-00050

SEAL,DUST

|K

707-44-90180

RING,PISTON

|K

07156-00912

RING,WEAR
