Запчасти Komatsu PC58SF-1 МЕХАНИЗМ ПОВОРОТА И МОТОР (МЕХАНИЗМ ПОВОРОТА) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|1

20U-26-00061

SWING MACHINERY A.

|1

20U-26-00060

SWING MACHINERY A.

1

20T-26-81180

CARRIER

2

20T-26-81121

GEAR

3

20S-26-81260

PIN

4

20T-26-81430

BEARING

5

20S-26-71160

WASHER

6

20S-26-71190

RING

7

20S-26-71250

PIN

8

20T-26-81190

CARRIER

9

20T-26-81140

GEAR

10

20T-26-81250

PIN

11

20T-26-71190

BEARING

12

20T-26-81151

GEAR

|12

20T-26-81150

GEAR

13

20T-26-81231

SPACER

14

20U-26-31110

SHAFT

|14

20U-26-22110

SHAFT

15

20T-26-71221

BEARING

16

20U-26-31150

BEARING

|16

20U-26-22160

BEARING

17

20T-26-81210

SEAL

18

20U-26-31160

CASE

|18

20U-26-22121

CASE

19

01253-61210

BOLT

20

01252-61290

BOLT

21

01643-51232

WASHER

22

20T-26-81240

WASHER

23

20U-26-31140

SEAL

|23

20T-26-81220

SEAL

24

20T-26-81110

GEAR

25

20T-26-81130

GEAR

26

07049-01215

PLUG

27

04064-04018

RING

28

708-7R-00210

MOTOR ASS'Y

|28

708-7R-00160

MOTOR ASS'Y

29

20S-26-81310

RING

30

708-7T-51210

O-RING

31

07236-10422

ELBOW

32

07002-12034

O-RING

33

21X-62-21140

ELBOW

34

07235-10422

ELBOW

35

07002-12034

O-RING

36

07235-10210

ELBOW

37

07002-01423

O-RING

38

07230-20210

UNION

39

07002-01423

O-RING

40

01010-81245

BOLT

41

01643-31232

WASHER

42

04020-01434

PIN,DOWEL
