Запчасти Komatsu PC57-7 КАПОТ (/) M [ЧАСТИ КОРПУСА]
![Схема запчастей Komatsu PC57-7 - КАПОТ (/) M [ЧАСТИ КОРПУСА]](https://partsell.ru/storage/images/komatsu/KC_EB006/m00088a.png)
31
25
24
23
1
6
7
5
29
30
27
28
26
4
3
2
9
8
10
12
16
16
20
21
11
15
14
17
19
25
18
24
22
13
23
|$1
22H-54-11705
HOOD ASS'Y
1
Ўо
HOOD
2
22H-54-12131
BRACKET
3
01010-81020
BOLT
4
01643-31032
WASHER
5
201-54-81991
LOCK ASS'Y
6
01010-81020
BOLT
7
01643-31032
WASHER
8
21U-54-21260
CATCH
9
22H-54-11461
SEAL
10
22H-54-11542
SHEET
11
22H-54-12270
SHEET
12
22H-54-12282
SHEET
13
22H-54-11391
ROD
14
01643-31032
WASHER
15
04052-21038
PIN
16
124-A62-1920
CAP
17
22H-54-11762
HINGE
18
01010-81020
BOLT
19
01643-31032
WASHER
20
01010-81020
BOLT
21
01643-31032
WASHER
22
22H-54-11680
DAMPER
23
04205-10825
PIN
24
01643-30823
WASHER
25
04052-20833
PIN
26
22H-54-11192
BRACKET
27
01010-81020
BOLT
28
01643-31032
WASHER
29
20Y-54-11611
STOPPER
30
01580-11008
NUT
31
22H-54-12241
SEAL
