Запчасти Komatsu PC55MR-3 МАРКИРОВКА (№-) МАРКИРОВКА, АНГЛ. INSTRUCTION, ДЛЯ СТРАН ЕС

1

09601-000J1

Plate, Name (Limited Supply)

2

04418-13060

Screw

3

21U-98-31160

Plate, Mark, Location Of Center Of Gravity

4

09960-70601

Mark, Lift Point

5

09960-01201

Mark, Lift Point and Tie Down Point Marks

6

09960-00602

Mark, Tie Down Point

7

22M-98-21330

Decal, Service Instruction, Greasing Point

8

22N-98-31370

Plate, Greasing, Lubrication

9

09963-A1640

Tag, Danger, Do Not Operate

10

09659-A057B

Plate, Warning, Explosion Hazard

11

09659-A057B

Plate, Warning, Explosion Hazard

12

14X-98-35181

Plate, Reflector

13

09134-A0881

Plate, Danger, Keep Off Working Area

14

09657-A0881

Plate, Warning, Track Adjustment

15

09653-A0361

Plate, Warning, High Temperature

16

09669-0000E

Plate, Symbol, Fuel Filler

17

22M-98-11540

Decal, Caution, Pressurise the Tank

18

22L-98-22180

Decal, Warning, Lock Lever

19

22L-98-22390

Decal, Danger, Lock Pin

20

22L-98-18140

Decal, Power Supply

21

21S-98-28330

Decal, Hydraulic Tank

22

09994-0030A

Tag, Caution, Antifreeze

23

22L-973-2241

Decal, 2-Way Select Valve

24

22M-98-27120

Plate, Name, PC55MR

25

22N-98-31151

Plate, Name, PC55MR

26

09690-P0560

Plate, Komatsu Logo

27

09690-P0560

Plate, Komatsu Logo

28

09651-A0481

Plate, Warning, Read Manual Before Operating

29

09654-A0481

Plate, Warning, Before Leaving Seat

30

09801-A0481

Plate, Danger, High Voltage Hazard

31

22L-98-22550

Decal, Symbol, Starting Switch Control

32

22L-98-22510

Decal, Warning, Lock Lever

33

20P-98-71510

Decal, Fuse Box

34

22L-98-22461

Decal, Balancing Position Mark

35

22M-98-31511

Oil Chart

36

22M-98-12110

Decal, Danger, Keep Off Swing Area

37

09824-K0481

Plate, Danger, Do Not Put Hands

38

22L-98-22450

Decal, Seat Adjustment

39

09659-A057B

Plate, Warning, Explosion Hazard

40

22M-98-12110

Decal, Danger, Keep Off Swing Area

41

09667-A0481

Plate, Caution, Rotating Object

42

09808-A0881

Plate, Warning, Battery Cables

43

09653-A0361

Plate, Warning, High Temperature

44

09651-A0481

Plate, Warning, Read Manual Before Operating

45

22F-98-17210

Decal, Caution, Engine Fuel Filter

46

21S-98-28970

Decal, Symbol, Fuel Filter

47

21S-98-28980

Decal, Symbol, Air Cleaner

48

22L-98-18290

Decal, Symbol, Engine Oil Filter

49

21S-98-28340

Decal, Symbol, Hydraulic Oil Level

50

21S-98-28350

Decal, Symbol, Hydraulic Oil Filter

51

22L-98-22530

Decal, Symbol, Radiator Cap

52

22L-98-22540

Decal, Caution, Coolant Level

53

09842-A0481

Plate, Warning, No Jump Start

54

203-00-31120

Plate, Instruction

55

22F-98-17220

Plate, Service Instruction, Bypass Oil Filter

56

21S-98-32171

Decal, Service Instruction, Air Cleaner

57

09642-13000

Plate, Service Instruction, Engine Coolant AF-NAC
