Запчасти Komatsu PC550LC-8 ГУСЕНИЧНАЯ РАМА, КОНЕЧНАЯ ПЕРЕДАЧА ЛЕВ. (№78-) ГУСЕНИЧНАЯ РАМА

|$0

21M-27-00041

Final Drive Assembly

|$1

17M-27-00102

Floating Seal Assembly

1

Seal

2

O-ring

3

21M-27-11210

Hub

4

208-27-62110

Bearing

5

208-27-51212

Cover

6

01010-81240

Bolt

7

01643-31232

Washer

8

21M-27-11280

O-ring

9

21M-27-00110

Spacer Assembly

9

Spacer, T=3.5mm

9

Spacer, T=3.25mm

9

Spacer, T=3.3mm

9

Spacer, T=3.35mm

9

Spacer, T=3.4mm

9

Spacer, T=3.45mm

9

Spacer, T=3.55mm

10

21M-27-11290

Retainer

11

208-27-52311

Bolt

12

21M-27-11380

Bolt

13

21M-27-11180

Carrier

14

21M-27-11140

Gear

15

21M-27-11230

Bearing

16

21M-27-11260

Washer, Thrust

17

21M-27-11250

Pin

18

20Y-27-21290

Pin

19

207-27-52270

Spacer

20

21M-27-11130

Gear

21

21M-27-11270

Washer, Thrust

22

21M-27-11150

Gear

23

21M-27-11160

Gear

24

21M-27-11170

Carrier

25

21M-27-11120

Gear

26

21M-27-11411

Bearing

27

20Y-27-21250

Washer, Thrust

28

21M-27-11240

Pin

29

20Y-27-21280

Pin

30

21M-27-11111

Shaft

31

20Y-27-11250

Spacer

32

208-27-61350

Button

33

21M-27-11190

Cover

34

208-27-52341

Bolt

35

01643-31845

Washer

36

07049-01215

Plug

37

07044-12412

Plug

38

07002-12434

O-ring

39

21M-27-11220

Sprocket

40

01010-82265

Bolt

41

01643-32260

Washer

42

01010-62490

Bolt

43

01643-32460

Washer
