Запчасти Komatsu PC550LC-8 ANTI-DROP КЛАПАН ТРУБЫ, СТРЕЛА ANTI-DROP КЛАПАН (/) (№78-) ANTI-DROP КЛАПАН ТРУБЫ

|$0

702-21-08720

Valve, Pilot

1

Valve Body

2

Spool

3

702-21-39480

Case

4

702-21-39420

Retainer, T=2.0mm

4

702-21-39460

Retainer, T=2.3mm

4

702-21-39470

Retainer, T=1.7mm

5

702-21-39430

Flange

6

702-21-39440

Spring

7

702-21-39330

Spring

8

709-62-31280

O-ring

9

702-21-39450

O-ring

10

702-21-38480

Plug

11

01252-60835

Bolt, Hexagon Socket Head

12

01252-60820

Bolt, Hexagon Socket Head

13

07000-13028

O-ring

14

Valve

15

709-94-91751

Spring

16

700-93-11320

O-ring

17

700-93-11330

Ring, Back-up

18

723-40-91500

Valve Assembly, Relief

19

700-80-64220

Ring, Back-up

20

700-22-11410

O-ring

21

709-25-11390

O-ring
