Запчасти Komatsu PC50UU-2 КОНЕЧНАЯ ПЕРЕДАЧА (МОТОР ХОДА /) (ГИДРАВЛ МОТОР /)(№99-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

20U-60-23331

MOTOR A.

|$3

20U-60-23330

TRAVEL MOTOR ASS'Y

|$5

TZ587B200000EY

MOTOR,HYDRAULIC

|$6

TZ578B200000EY

MOTOR,HYDRAULIC

1

TZ587B210100-J

FLANGE KIT,REAR

1

TZ578B210100-J

FLANGE KIT,REAR

2

TZGM1-8-S

PLUG

2

TZGM1-8

PLUG

3

TZGDL1-16-S

PLUG

4

TZ587B2044-00

ORIFICE

4

TZ578B2044-00

ORIFICE

5

TZ121F2070-00

ORIFICE

6

TZ850A0006-00

PLATE, NAME

7

04260-00793

BALL

8

TZ510B2004-01

BLOCK,CYLINDER

9

TZ510B2105-00

PISTON KIT (9 PIS)

10

TZ573B200300-E

PLATE,SWASH

11

TZ310B2032-01

PLATE,THRUST

12

TZ310B2007-01

PLATE,RETAINER

13

TZ310B2008-00

BOWL,THRUST

14

TZJB1506-2-208

PIN

15

TZ510B2014-00

SPRING

16

TZ310B2010-00

WASHER

17

TZIRTW-32

RING,SNAP

18

TZ310B2074-00

PLATE

19

TZ550A2015-00

DISK

20

TZ550A2016-00

PLATE

21

TZ577B2012-00

PISTON

22

TZ571B2039-01

O-RING (K1)

23

TZ571B2035-01

O-RING (K1)

24

TZ550A2013-00

SPRING

25

TZ550A2009-00

PLATE,TIMING

26

06000-06201

BEARING,BALL

27

TZ573B2002-00

SHAFT

28

TZ510B2029-00

BEARING,BALL

29

TZ15Z-17-35-8

SEAL,OIL (K1)

30

TZ573B2070-00

PISTON ASS'Y

31

TZ573B2085-00

SPRING

32

TZ534B2076-00

PIVOT

33

TZ534B2077-00

PIN

34

TZJB1354-4-10

PIN
