Запчасти Komatsu PC50UU-2 МОТОР ПОВОРОТА (/) (TBG/ EC СПЕЦ-Я.)(№97-88) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-7T-00160

SWING MOTOR ASS'Y

1

708-7T-11240

CASE,MOTOR

2

708-7T-11650

COVER,END

3

708-7T-51210

O-RING

4

720-68-19610

PIN

5

01010-81250

BOLT

6

708-7T-12310

SHAFT

7

708-7T-12240

BEARING

8

708-7T-12250

BEARING

9

708-7T-12230

SEAL,OIL

10

04065-04518

RING,SNAP

11

708-7T-05020

SPACER KIT

11

SPACER, 1.6MM

11

SPACER, 1.7MM

11

SPACER, 1.8MM

11

SPACER, 1.9MM

11

SPACER, 2.0MM

11

SPACER, 2.1MM

11

SPACER, 2.2MM

12

708-7T-13421

PLATE,THRUST

13

708-7T-13510

GUIDE,RETAINER

14

708-7T-13710

SPACER

15

708-7T-13570

SPRING

16

708-7T-13530

WASHER

17

708-7T-13540

PIN

18

04065-03815

RING,SNAP

19

708-7T-13611

PISTON SUB ASS'Y

20

708-7T-13342

RETAINER,SHOE

21

708-7T-13140

BLOCK,CYLINDER

22

708-7T-13261

PLATE,VALVE

23

706-73-72420

VALVE

24

706-73-72440

SPRING

25

706-73-72430

PLUG

26

07002-12434

O-RING

27

708-7T-52512

PLATE

28

708-7T-15120

DISC

29

708-7T-15140

PISTON,BRAKE

30

07000-12130

O-RING

31

708-7T-55220

O-RING

32

708-7T-15150

SPRING
