Запчасти Komatsu PC50UU-2 МЕХАНИЗМ ПОВОРОТА И МОТОР (МЕХАНИЗМ ПОВОРОТА)(№7-) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|$3

20U-26-00043

SWING MACHINERY A.

|$4

20U-26-00042

SWING MACHINERY A.

|$5

20U-26-00041

SWING MACHINERY A.

1

20T-26-81180

CARRIER

2

20T-26-81121

GEAR

3

20S-26-81260

PIN

4

20T-26-81430

BEARING

5

20S-26-71160

WASHER

6

20S-26-71190

RING

7

20S-26-71250

PIN

8

20T-26-81190

CARRIER

9

20T-26-81140

GEAR

10

20T-26-81250

PIN

11

20T-26-71190

BEARING

12

20T-26-81151

GEAR

12

20T-26-81150

GEAR

13

20T-26-81231

SPACER

14

20U-26-22110

SHAFT

15

20T-26-71221

BEARING

16

20U-26-22160

BEARING

17

20T-26-81210

SEAL

18

20U-26-22121

CASE

18

20U-26-22120

CASE

19

01253-61210

BOLT

20

01252-61290

BOLT

21

01643-51232

WASHER

22

20T-26-81240

WASHER

23

20T-26-81220

SEAL

24

20T-26-81110

GEAR

25

20T-26-81130

GEAR

26

07049-01215

PLUG

27

04064-04018

RING

28

20U-26-22130

SHIM, 0.8MM

29

20U-26-22140

SHIM, 0.1MM

30

20U-26-22150

SHIM, 1.0MM

31

708-7R-00190

MOTOR ASS'Y

31

708-7R-00053

MOTOR ASS'Y

31

708-7R-00052

MOTOR ASS'Y

31

708-7R-00051

MOTOR ASS'Y

32

20S-26-81310

RING

33

708-7T-51210

O-RING

34

07236-10422

ELBOW

35

07002-12034

O-RING

36

21X-62-21140

ELBOW

37

07235-10422

ELBOW

38

07002-12034

O-RING

39

07235-10210

ELBOW

40

07002-01423

O-RING

41

07230-20210

UNION

42

07002-01423

O-RING

43

01010-81245

BOLT

44

01643-31232

WASHER

45

04020-01434

PIN
