Запчасти Komatsu PC50UU-2 ОСНОВН. КОНСТРУКЦИЯ (ЭЛЕКТРИКА) (ДЛЯ MONO СТРЕЛА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20U-54-23274

BRACKET

1

20U-54-23273

BRACKET

1

20U-54-23272

BRACKET

1

20U-54-23271

BRACKET

2

01010-81020

BOLT

3

01643-31032

WASHER

4

20T-06-71650

RELAY,SAFETY

5

01220-40612

SCREW

6

01602-20619

WASHER,SPRING

7

01641-20608

WASHER

8

08038-00519

CAP

9

01220-40612

SCREW

10

01643-30623

WASHER

11

01602-20619

WASHER,SPRING

12

21Y-06-11260

BUZZER ASS'Y

12

20T-06-71320

BUZZER ASS'Y

13

21Y-06-11270

PLATE

14

01220-40616

SCREW

15

01643-30623

WASHER

16

01602-20619

WASHER,SPRING

17

20T-06-71770

SWITCH,P.P.C. LOCK

17

20T-06-71520

SWITCH,P.P.C. LOCK

18

20U-43-21360

SCREW

19

01641-20508

WASHER

20

20T-06-71532

HARNESS,WIRING

20

20T-06-71531

HARNESS,WIRING

21

20T-06-71750

RELAY ASS'Y,ENGINE STOP MOTOR

21

21X-06-12310

RELAY ASS'Y,ENGINE STOP MOTOR

22

20T-06-71760

TIMER,ENGINE STOP MOTOR

23

01220-40612

SCREW

23

01220-40612

SCREW

24

01643-30623

WASHER

24

01643-30623

WASHER

25

01602-20619

WASHER,SPRING

25

01602-20619

WASHER,SPRING
