КАБИНА

Запчасти Komatsu PC50UU-2 КАБИНА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

Схема запчастей Komatsu PC50UU-2 - КАБИНА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
1
1
1A
1B
2
3
4
5
6
7
7
7A
8
8
9
9
9
9A
10
11
12
13
14
15
16
17
18
19
19
20
21
22
23
24
25
25
26
27
28
28
29
30
31
32
33
34
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$6

20U-54-00059

CAB ASS'Y

|$7

20U-54-00058

CAB ASS'Y

|$8

20U-54-00057

CAB ASS'Y

|$9

20U-54-00056

CAB ASS'Y

|$10

20U-54-00055

CAB ASS'Y

|$11

20U-54-00054

CAB ASS'Y

|$12

20U-54-00053

CAB ASS'Y

|$13

20U-54-00052

CAB ASS'Y

|$14

20U-54-00051

CAB ASS'Y

|$15

20U-54-00050

CAB ASS'Y

|$16

20U-54-00173

CAB ASS'Y,(WITH HEAD GUARD)

|$17

20U-54-00172

CAB ASS'Y,(WITH HEAD GUARD)

|$18

20U-54-00171

CAB ASS'Y,(WITH HEAD GUARD)

|$19

20U-54-00170

CAB ASS'Y,(WITH HEAD GUARD)

1

CAB

1

CAB

1

CAB

1

CAB

1

CAB ASS'Y,(WITH HEAD GUARD)

1

CAB,(WITH HEAD GUARD)

1A

01435-41020

BOLT

1A

113-B44-1230

BOLT

1B

01643-51032

WASHER

2

20T-54-84750

WINDOW,L.H., UPPER

2

20U-54-24752

WINDOW,L.H., UPPER

2

20U-54-24751

WINDOW,L.H., UPPER

3

20U-54-24971

DAM

4

20U-54-25151

TRIM

5

20T-54-84760

WINDOW,L.H., LOWER

5

20U-54-24761

WINDOW,L.H., LOWER

6

20U-54-24981

DAM

7

20U-54-26521

WINDOW,REAR

7

21W-54-34770

WINDOW,REAR

7

20U-54-24772

WINDOW,REAR

7

20U-54-24771

WINDOW,REAR

7A

20U-54-26531

PLATE

8

20U-54-24991

DAM

9

20U-54-25161

TRIM

9

20U-54-25161

TRIM

9A

20U-54-25162

SEAL

10

20U-54-26560

LINING,REAR

10

20U-54-24861

LINING,REAR

10

20U-54-24860

LINING,REAR

11

20U-54-24871

LINING,L.H.

12

20U-54-24881

LINING,R.H.

13

20U-54-25542

COVER,REAR

13

20U-54-25540

COVER,REAR

14

20U-54-25170

SEAL

15

20T-54-75122

DUCT

15

20T-54-75121

DUCT

15

20T-54-75120

DUCT

16

08059-00310

CLIP

16

21W-54-14690

CLIP

16

21W-54-14690

CLIP

17

20U-54-24681

TAPE

17

20U-54-24681

TAPE

18

20U-54-25510

SEAL

19

20U-54-25140

STOPPER

20

20T-54-84960

SHEET,NONSKID

20

20U-54-25530

SHEET,NONSKID

21

20U-54-24711

GLASS

22

20U-54-24721

STRIP,WEATHER

23

20U-54-24733

WINDOW,UPPER

23

20U-54-24732

WINDOW,UPPER

23

20U-54-24731

WINDOW,UPPER

24

20U-54-24741

STRIP,WEATHER

25

20T-54-75210

GROMMET

26

08037-01008

GROMMET

27

08037-02512

GROMMET

27

08037-02512

GROMMET

27

08037-01610

GROMMET

28

09415-01008

CAP

28

09415-01008

CAP

29

09415-00706

CAP

30

01023-20412

SCREW

30

01220-40412

SCREW

31

01641-20405

WASHER

32

01023-20612

SCREW

32

01220-40612

SCREW

33

01641-20608

WASHER

34

01370-40412

SCREW

Выбрано товаров: 81
