Запчасти Komatsu PC50UU-2 ОСНОВН. КЛАПАН (-КЛАПАН) (ДЛЯ КЛАПАН¤ ПРАВ.) (/) (MONO СТРЕЛА)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20U-60-22280

VALVE ASS'Y

1

NAD33216861401

BLOCK

2

BLOCK

3

BLOCK

4

NAD33216861601

BLOCK

5

NAC01200055010

O-RING

6

NAE51413047145

STUD

7

NAB01011008004

NUT

8

SPOOL,ARM

9

SPOOL,TRAVEL¤ L.H.

10

SPOOL,ARM HIGH

11

NAD33416498801

POPPET

12

NAD33416498901

SPRING

13

NAD33416884501

JOINT

14

NAC01100006010

O-RING

15

NAD33416861901

RETAINER

16

NAE57416861701

SPRING

17

NAD33416861801

CASE

18

NAC01100022010

O-RING

19

NAA02010604051

BOLT

20

NAD33414362401

RETAINER

21

NAE57416982101

SPRING

22

NAE51417062001

BOLT

23

NAD33414760401

CASE

24

NAE55414586501

SEAL,OIL

25

NAD33090604004

PLATE

26

NAE51416985101

BOLT

27

NAA02010601051

BOLT

28

NAD33417236801

POPPET

29

NAE57417237001

SPRING

30

NAD33417236901

PLUG

31

NAC01100014010

O-RING

32

07040-11007

PLUG

33

07002-11023

O-RING

34

NAD33316087822

VALVE ASS'Y,MAIN RELIEF

35

NAD33415778005

VALVE ASS'Y,SAFETY AND SUCTION

36

NAD33416379404

VALVE ASS'Y,SAFETY AND SUCTION

37

NAD33416379404

VALVE ASS'Y,SAFETY AND SUCTION
