Запчасти Komatsu PC50UU-2 ОСНОВН. КЛАПАН (5-СЕКЦИОНН.) (ДЛЯ КЛАПАН ЛЕВ.)(/)(НАКЛОНЯЕМ. МЕХАНИЧ. ANGLE/ НАВЕСН. ОБОРУД/ ТЕЛЕСКОПИЧЕСК. РУКОЯТЬ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

709-35-12300

VALVE ASS'Y

|1

709-35-11700

VALVE ASS'Y

|1

709-35-11500

VALVE ASS'Y

|1

709-20-53900

VALVE ASS'Y

|1

700-28-51000

VALVE ASS'Y

1

SLEEVE

2

POPPET

3

SPRING

4

SCREW

5

O-RING

6

NUT

|6

NUT

7

700-22-11410

O-RING

8

07002-02434

O-RING

9

RING

10

VALVE

11

SPRING

|12

709-30-64900

VALVE ASS'Y,SUCTION AND SAFETY

12

SLEEVE

13

VALVE

14

POPPET

15

PISTON

16

SCREW

17

O-RING

18

NUT

19

SPRING

20

PLUG

21

SEAL

22

O-RING

23

07002-02034

O-RING

24

SPRING

25

SEAL

|26

709-30-64101

VALVE ASS'Y,SUCTION AND SAFETY

26

SLEEVE

27

VALVE

28

POPPET

29

PISTON

30

SCREW

31

O-RING

32

NUT

33

SPRING

34

PLUG

35

SEAL

36

O-RING

37

07002-02034

O-RING

38

SPRING

39

SEAL

|40

709-30-63702

VALVE ASS'Y,SUCTION AND SAFETY

40

SLEEVE

41

VALVE

42

POPPET

43

SPRING

44

PISTON

45

SCREW

46

O-RING

47

SPRING

48

NUT

49

PLUG

50

SEAL

51

07002-02034

O-RING

52

SEAL

53

O-RING

|54

709-30-61100

VALVE ASS'Y,SUCTION

|54

709-30-61100

VALVE ASS'Y,SUCTION

54

SLEEVE

55

VALVE

56

SEAL

57

SPRING

58

07002-02034

O-RING
