Запчасти Komatsu PC50UU-2 КОНЕЧНАЯ ПЕРЕДАЧА (МОТОР ХОДА /) (ГИДРАВЛ МОТОР)(№77-99) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20U-60-23320

TRAVEL MOTOR ASS'Y

|1

TZ538B200001EU

MOTOR,HYDRAULIC

1

TZ538B211100-U

FLANGE KIT,REAR

2

TZGM1-8

PLUG

3

TZMB700-060

PLUG

4

TZ300B2044-00

ORIFICE

5

TZ121F2070-00

ORIFICE

6

TZ850A0006-00

PLATE¤ NAME

7

TZ538B2052-00

STOPPER

8

TZ510B2056-00

SPRING

9

TZ300A2051-00

PLUG

10

TZJB2401-P22-9

O-RING (K1)

11

TZ300A2054-00

VALVE

12

TZ300A2055-00

SPRING

13

TZ300A2053-00

PLUG

14

07000-12012

O-RING (K1)

15

TZGM1-4-K

PLUG

16

TZ200B2073-00

VALVE

17

TZ300B2039-00

STOPPER

18

TZ300B2043-01

SPRING

19

TZ300B2042-00

RING

20

TZ510B2002-01

SHAFT

21

TZ510B2029-00

BEARING,BALL

22

TZ15Z-17-35-8

SEAL,OIL (K1)

23

TZ512B2004-00

BLOCK,CYLINDER

24

TZ310B2007-01

PLATE,RETAINER

25

TZ510B2105-00

PISTON KIT (9 PIS)

26

TZ310B200301-E

PLATE,SWASH

27

TZ310B2032-01

PLATE,THRUST

28

TZ310B2008-00

BOWL,THRUST

29

TZ310B2070-01

PISTON ASS'Y

30

TZ534B2076-00

PIVOT

31

TZJB1506-2-208

PIN

32

TZ510B2014-00

SPRING

33

TZ310B2010-00

WASHER

34

TZIRTW-32

RING,SNAP

35

TZ550A2009-00

PLATE,TIMING

36

06000-06201

BEARING,BALL

37

TZJB1354-4-10

PIN

38

TZGM1-8

PLUG

39

04260-00793

BALL

40

01252-30820

BOLT

41

TZJB1354-8-16

PIN

42

TZ534B2077-00

PIN
