Запчасти Komatsu PC50UU-2 МОТОР ПОВОРОТА (/)(№77-99) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-7T-00180

MOTOR ASS'Y

1

708-7T-11240

CASE,MOTOR

2

708-7T-11650

COVER,END

3

708-7T-51210

O-RING

4

720-68-19610

PIN

5

01010-81250

BOLT

6

708-7T-12310

SHAFT

7

708-7T-12240

BEARING

8

708-7T-12250

BEARING

9

708-7T-12230

SEAL,OIL

10

04065-04518

RING,SNAP

11

708-7T-05020

SPACER KIT

|11

SPACER¤ 1.6MM

|11

SPACER¤ 1.7MM

|11

SPACER¤ 1.8MM

|11

SPACER¤ 1.9MM

|11

SPACER¤ 2.0MM

|11

SPACER¤ 2.1MM

|11

SPACER¤ 2.2MM

12

708-7T-13421

PLATE,THRUST

13

708-7T-13510

GUIDE,RETAINER

14

708-7T-13710

SPACER

15

708-7T-13570

SPRING

16

708-7T-13530

WASHER

17

708-7T-13540

PIN

18

04065-03815

RING,SNAP

19

708-7T-13611

PISTON SUB ASS'Y

20

708-7T-13342

RETAINER,SHOE

21

708-7T-13140

BLOCK,CYLINDER

22

708-7T-13261

PLATE,VALVE

23

706-73-72420

VALVE

24

706-73-72440

SPRING

25

706-73-72430

PLUG

26

07002-12434

O-RING

27

07040-11409

PLUG

28

07002-01423

O-RING
