Запчасти Komatsu PC50UU-2 SLIDE ЦИЛИНДР РУКОЯТИ(ТЕЛЕСКОПИЧЕСК. РУКОЯТЬ) (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

20U-63-X2394

SLIDE CYLINDER G.,SLIDE ARM

G1

20U-63-X2393

SLIDE CYLINDER G.,SLIDE ARM

G1

20U-63-X2392

SLIDE CYLINDER G.,SLIDE ARM

|1

20U-63-02394

CYLINDER ASS'Y,SLIDE ARM

|1

20U-63-02393

CYLINDER ASS'Y,SLIDE ARM

|1

20U-63-02392

CYLINDER ASS'Y,SLIDE ARM

1

20U-63-99242

CYLINDER

|1

20U-63-99241

CYLINDER

2

20U-63-99222

ROD,PISTON

3

707-76-35320

BUSHING

|3

07143-10304

BUSHING

4

07145-00035

SEAL,DUST (KIT)

5

707-29-60760

HEAD,CYLINDER

6

175-63-75190

SEAL,DUST (KIT)

7

07179-12047

RING,SNAP

8

07177-03525

BUSHING

9

707-51-35210

PACKING,ROD (KIT)

10

07000-02060

O-RING (KIT)

11

07000-12055

O-RING (KIT)

12

07146-02056

RING,BACK-UP (KIT)

13

707-36-60140

PISTON

14

707-44-60180

RING,PISTON (KIT)

15

707-39-60190

RING,WEAR (KIT)

16

01580-02419

NUT

17

20U-63-99370

TUBE

18

20U-63-99381

TUBE

|18

20U-63-99380

TUBE

19

07283-21529

CLIP

20

01598-00809

NUT

21

01643-30823

WASHER
