Запчасти Komatsu PC50UU-2 ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

20U-63-X2314

ARM CYLINDER GROUP

G1

20U-63-X2313

ARM CYLINDER GROUP

G1

20U-63-X2312

ARM CYLINDER GROUP

|1

20U-63-02314

CYLINDER ASS'Y,ARM

|1

20U-63-02313

CYLINDER ASS'Y,ARM

|1

20U-63-02312

CYLINDER ASS'Y,ARM

1

20U-63-66443

CYLINDER,ARM

|1

20U-63-66442

CYLINDER,ARM

2

707-76-55440

BUSHING

|2

07144-10504

BUSHING

3

07145-00055

SEAL,DUST (KIT)

4

707-29-90320

HEAD,CYLINDER

5

07177-05530

BUSHING

6

707-51-55211

PACKING,ROD (KIT)

7

707-56-55510

SEAL,DUST (KIT)

8

07179-12069

RING,SNAP

9

07000-12085

O-RING (KIT)

10

07146-02086

RING,BACK-UP (KIT)

11

707-35-52690

RING,BACK-UP (KIT)

12

07000-02090

O-RING (KIT)

13

20U-63-66422

ROD,PISTON

|13

20U-63-66421

ROD,PISTON

14

20T-870-1290

BUSHING

|14

07144-10505

BUSHING

15

07145-00050

SEAL,DUST (KIT)

16

07020-00000

FITTING,GREASE

17

707-71-60540

PLUNGER

18

707-36-90260

PISTON

19

707-44-90180

RING,PISTON (KIT)

20

07156-00912

RING,WEAR (KIT)

21

707-40-90390

WASHER

22

01580-03629

NUT

23

707-71-60050

PLUNGER

24

04260-00635

BALL

25

707-71-91290

PLUG

26

07165-13638

NUT

27

20U-63-66472

TUBE

|27

20U-63-66471

TUBE

28

20U-63-66483

TUBE

|28

20U-63-66482

TUBE

29

01010-81025

BOLT

|29

01010-51025

BOLT

30

01643-31032

WASHER
