Запчасти Komatsu PC50UU-2 МЕХАНИЗМ ПОВОРОТА И МОТОР (МЕХАНИЗМ ПОВОРОТА)(№77-99) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|1

20U-26-00021

SWING MACHINERY A.

1

20T-26-71180

GEAR

2

20T-26-71190

BEARING

3

20T-26-71211

SHAFT

4

20S-26-71160

WASHER,THRUST

5

20S-26-71190

RING,SNAP

6

20S-26-71250

PIN

7

20T-26-71170

GEAR,RING

8

20T-26-71132

CARRIER

9

20T-26-71311

SPACER

10

20U-26-21120

SHAFT

11

20T-26-71221

BEARING

12

20T-26-71231

BEARING

13

20T-26-71151

COLLAR

14

07000-02060

O-RING

15

07012-00090

SEAL,OIL

16

20U-26-21140

CASE

17

20T-26-71111

SPACER

18

01252-41050

BOLT

19

01643-31032

WASHER

20

20T-26-71330

CAP

21

20U-26-21220

FILLER

22

20T-26-71320

PIPE

23

07042-30211

PLUG

24

07049-01215

PLUG

25

07049-01012

PLUG

26

07042-20108

PLUG

27

20U-26-21250

SPACER

28

07235-10210

ELBOW

29

07002-01423

O-RING

30

01010-51040

BOLT

31

01643-31032

WASHER

32

708-7T-00180

MOTOR ASS'Y

33

07235-10315

ELBOW

34

07002-12034

O-RING

35

203-62-32950

ELBOW

36

07002-02434

O-RING

37

20T-62-71640

ELBOW

38

07002-02034

O-RING

39

01010-51245

BOLT

40

01643-31232

WASHER

41

04020-01434

PIN,DOWEL
