Запчасти Komatsu PC50UU-2 ОХЛАЖД-Е (РАДИАТОР И МАСЛООХЛАДИТЕЛЬ) СИСТЕМА ОХЛАЖДЕНИЯ

1

20U-03-21261

CORE ASS'Y,RADIATOR

|1

20U-03-21260

CORE ASS'Y,RADIATOR

|1

20T-03-71110

CORE ASS'Y,RADIATOR

2

20U-03-21240

SHROUD

|2

20T-03-71121

SHROUD

3

01010-80814

BOLT

4

01643-30823

WASHER

5

205-03-62660

PLUG

6

07000-01007

O-RING

7

20U-03-21540

CAP

|7

104-03-41230

CAP

|7

201-03-51310

CAP

8

07270-00827

TUBE

9

20U-03-21211

COVER

|9

20U-03-21210

COVER

10

20U-03-21220

COVER

11

01010-80814

BOLT

12

01643-30823

WASHER

13

20U-03-21230

SEAL

14

20T-03-71750

SEAL

15

08037-01610

GROMMET

16

20U-03-21114

OIL COOLER ASS'Y

|16

20U-03-21112

OIL COOLER ASS'Y

|16

20U-03-21111

OIL COOLER ASS'Y

17

01010-80820

BOLT

18

01643-30823

WASHER

19

20U-03-21251

NET,WIRE

|19

20U-03-21250

NET,WIRE

|19

20T-03-71131

NET,WIRE

20

01010-80814

BOLT

21

01643-30823

WASHER

22

08036-01214

CLIP

23

20U-03-21520

HOSE

|23

20T-03-71210

HOSE

24

07289-00045

CLAMP

|24

207-09-11110

CLAMP

25

20U-03-21531

HOSE

|25

20U-03-21530

HOSE

|25

20T-03-71220

HOSE

26

07289-00045

CLAMP

|26

207-09-11110

CLAMP

27

20T-03-71760

SHEET

28

20T-03-71160

PLATE

29

01010-81025

BOLT

30

01643-31032

WASHER

31

203-03-56330

CUSHION

32

01580-11008

NUT

33

01643-31032

WASHER

34

20U-03-21411

BRACKET

|34

20U-03-21410

BRACKET

35

01010-81030

BOLT

36

01643-31032

WASHER

37

203-03-56330

CUSHION

38

01580-11008

NUT

39

01643-31032

WASHER

40

20U-03-21420

SHEET

41

20U-03-21441

SHEET

|41

20U-03-21441

SHEET
