Запчасти Komatsu PC50UU-2 КАБИНА (КОРПУС)(№99-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

20U-54-00059

CAB ASS'Y

|1

20U-54-00058

CAB ASS'Y

|1

20U-54-00057

CAB ASS'Y

|1

20U-54-00056

CAB ASS'Y

|1

20U-54-00173

CAB ASS'Y,(WITH HEAD GUARD)

|1

20U-54-00172

CAB ASS'Y,(WITH HEAD GUARD)

|1

20U-54-00171

CAB ASS'Y,(WITH HEAD GUARD)

|1

20U-54-00170

CAB ASS'Y,(WITH HEAD GUARD)

1

20U-54-24671

.BRACKET

2

01010-D0816

.BOLT

3

01643-70823

.WASHER

4

205-54-63311

.LOCK ASS'Y

|4

205-54-63310

.LOCK ASS'Y

5

01010-D0616

.BOLT

6

01643-70823

.WASHER

7

20T-54-84620

.STOPPER,L.H.

|7

20T-54-74311

.STOPPER,L.H.

8

20T-54-84630

.STOPPER,R.H.

|8

20T-54-74331

.STOPPER,R.H.

9

20Y-54-14280

.SCREW

10

205-54-71560

.TRIM

11

20U-54-24652

.SEAL,FRONT

|11

20U-54-24651

.SEAL,FRONT

12

01641-21016

.WASHER

13

20U-54-24592

.GLASS,FRONT¤ LOWER

14

22M-54-14560

.LATCH,L.H.

|14

20U-54-24611

.LATCH,L.H.

15

22M-54-14570

.LATCH,R.H.

|15

20U-54-24621

.LATCH,R.H.

16

20T-54-32780

.PACKING

17

20T-54-32870

.PACKING¤ 1.0MM

18

20T-54-32750

.PACKING¤ 2.0MM

19

20T-54-32760

.RETAINER,L.H.

20

20T-54-32770

.RETAINER,R.H.

21

01220-20512

.SCREW

22

01601-20513

.WASHER

23

20U-54-24792

.GLASS,REAR¤ UPPER

24

205-54-51720

.RETAINER

25

205-54-51730

.PACKING

26

01224-70610

.SCREW

27

20U-54-25970

.LOCK,QUARTER¤ L.H.

|27

20U-54-25980

.LOCK,QUARTER¤ R.H.

|27

20U-54-25640

.LOCK,QUARTER

28

01224-70510

.SCREW

29

01584-00504

.NUT

30

20U-54-24814

.WIRING

|30

20U-54-24813

.WIRING

|30

20U-54-24812

.WIRING

31

21W-54-14691

.CLIP

32

08059-00310

.CLIP

|32

21W-54-14690

.CLIP

33

20T-54-84610

...PLATE

|33

20T-54-84610

.PLATE

34

01370-40412

.SCREW

|34

01370-00412

.SCREW

35

205-54-51250

.HANGER

36

01225-70412

.SCREW

37

20U-54-25570

.CAP

38

20U-54-25180

.COVER

39

01220-70612

.SCREW

40

01643-70623

.WASHER

41

20U-54-24781

.GUARD

42

01010-D0820

.BOLT

43

01643-70823

.WASHER
