Запчасти Komatsu PC50UU-2 P.P.C. ОСНОВН. ЛИНИЯ (-WAY КЛАПАН ТРУБЫ) (MULTIPLE PATTERN УПРАВЛ-Е)(№99-) ГИДРАВЛИКА

1

20U-62-23702

VALVE ASS'Y,(SEE FIG.Y1687-01A2)

|1

20U-62-23701

VALVE ASS'Y,(SEE FIG.Y1687-01A2)

2

20U-62-23770

ELBOW

3

07002-01423

O-RING

4

07235-10210

ELBOW

5

07002-01423

O-RING

6

07230-20210

UNION

7

07002-01423

O-RING

8

21X-62-22270

HOSE¤ 250MM,BLACK

|8

20U-62-22190

O-RING

9

21X-62-22270

HOSE¤ 250MM,RED

|9

20U-62-22190

O-RING

10

21X-62-22270

HOSE¤ 250MM,ORANGE

|10

20U-62-22190

O-RING

11

21X-62-22270

HOSE¤ 250MM,WHITE

|11

20U-62-22190

O-RING

12

21X-62-22270

HOSE¤ 250MM,BROWN

|12

20U-62-22190

O-RING

13

20U-62-23421

HOSE,YELLOW

14

20U-62-23421

HOSE,WHITE

15

21X-62-22260

HOSE,GREEN

16

20U-62-23550

BAND¤ ORANGE

17

20Y-62-22790

BAND¤ RED

18

20Y-62-22820

BAND¤ BLUE

19

20Y-62-22840

BAND

20

20Y-62-22830

BAND¤ WHITE

21

20Y-62-22860

BAND¤ BROWN

22

01010-81040

BOLT

23

01643-31032

WASHER

24

08034-00823

BAND

25

09822-A1110

PLATE¤ OPERATING,JIS AND OLD KOMATSU PATTERN

|25

20Y-00-11310

PLATE¤ OPERATING,KOMATSU PATTERN

26

09822-A1120

PLATE¤ OPERATING,OLD MITSUBISHI AND OLD SINKOU

|26

203-916-5130

PLATE¤ OPERATING,MITSUBISHI PATTERN

27

09822-00010

PLATE¤ SAFETY,MULTIPLE PATTERN

|27

203-916-5150

PLATE¤ OPERATING,SINKOU PATTERN

28

09822-00020

CASE¤ PLATE

|28

203-916-5730

PLATE¤ OPERATING,ISO PATTERN

29

09822-01200

PLATE¤ SAFETY,MULTIPLE PATTERN

|29

09822-11200

PLATE¤ OPERATING,MULTIPLE PATTERN

|29

20U-54-23371

PLATE¤ OPERATING,MULTIPLE PATTERN

30

22F-98-11311

PLATE¤ CAUTION

|30

01023-60314

SCREW

31

20U-98-22660

PLATE

|31

20U-98-31160

PLATE,SHIFT PATTERN

|31

01580-10302

NUT
