Запчасти Komatsu PC50UU-2 ОХЛАЖД-Е (РАДИАТОР И МАСЛООХЛАДИТЕЛЬ) (EC СПЕЦ-Я.) СИСТЕМА ОХЛАЖДЕНИЯ

1

20U-03-21261

CORE ASS'Y

1

20U-03-21260

CORE ASS'Y

1

20T-03-71110

CORE ASS'Y

2

20U-03-21240

SHROUD

2

20T-03-71121

SHROUD

3

01010-80814

BOLT

4

01643-30823

WASHER

5

205-03-62660

PLUG

6

07000-01007

O-RING

7

104-03-41230

CAP

7

201-03-51310

CAP

8

07270-00827

TUBE

9

20U-03-21211

COVER

9

20U-03-21210

COVER

10

20U-03-21220

COVER

11

01010-80814

BOLT

12

01643-30823

WASHER

13

20U-03-21230

SEAL

14

20T-03-71750

SEAL

15

08037-01610

GROMMET

16

20U-03-21112

OIL COOLER ASS'Y

16

20U-03-21111

OIL COOLER ASS'Y

17

01010-50820

BOLT

18

01643-30823

WASHER

19

20U-03-21251

NET,WIRE

19

20U-03-21510

NET,WIRE

20

01010-50814

BOLT

21

01643-30823

WASHER

22

08036-01214

CLIP

23

20U-03-21520

HOSE

23

20T-03-71210

HOSE

24

207-09-11110

CLAMP

25

20U-03-21531

HOSE

25

20U-03-21530

HOSE

25

20T-03-71220

HOSE

26

207-09-11110

CLAMP

27

20T-03-71760

SHEET

28

20T-03-71160

PLATE

29

01010-51025

BOLT

30

01643-31032

WASHER

31

203-03-56330

CUSHION

32

01580-11008

NUT

33

01643-31032

WASHER

34

20U-03-21411

BRACKET

34

20U-03-21410

BRACKET

35

01010-51030

BOLT

36

01643-31032

WASHER

37

203-03-56330

CUSHION

38

01580-11008

NUT

39

01643-31032

WASHER

40

20U-03-21420

SHEET

41

20U-03-21441

SHEET

41

20U-03-21440

SHEET
