Запчасти Komatsu PC50UU-2 КАБИНА (EC СПЕЦ-Я.) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$1

20U-54-00088

CAB ASS'Y

|$2

20U-54-00087

CAB ASS'Y

|$3

20U-54-00086

CAB ASS'Y

|$4

20U-54-00085

CAB ASS'Y

|$5

20U-54-00081

CAB ASS'Y

1

20U-54-25713

CAB

1

20U-54-25712

CAB

1

CAB

1A

113-B44-1230

BOLT

1B

01643-51032

WASHER

2

20T-54-84750

WINDOW,L.H. UPPER

2

20U-54-24751

WINDOW,L.H. UPPER

3

20U-54-24971

DAM

4

20U-54-25151

TRIM

5

20T-54-84760

WINDOW,L.H. LOWER

5

20U-54-24761

WINDOW,L.H. LOWER

6

20U-54-24981

DAM

7

21W-54-34770

WINDOW,REAR

7

20U-54-24771

WINDOW,REAR

8

20U-54-24991

DAM

9

20U-54-25161

TRIM

9

20U-54-25161

TRIM

9A

20U-54-25162

SEAL

10

20U-54-24861

LINING,REAR

10

20U-54-24860

LINING,REAR

11

20U-54-24871

LINING,L.H.

12

20U-54-24881

LINING,R.H.

13

20U-54-25540

COVER,REAR

14

20U-54-25170

SEAL

15

20T-54-75121

DUCT

15

20T-54-75120

DUCT

16

21W-54-14690

CLIP

16

21W-54-14690

CLIP

17

20U-54-24681

TAPE

18

20U-54-25510

SEAL

19

20U-54-25140

STOPPER

20

20T-54-84960

SHEET

20

20U-54-25530

SHEET

21

20U-54-24711

GLASS

22

20U-54-24721

STRIP,WEATHER

23

20U-54-24733

WINDOW,UPPER

23

20U-54-24732

WINDOW,UPPER

23

20U-54-24731

WINDOW,UPPER

24

20U-54-24741

STRIP,WEATHER

25

20T-54-75210

GROMMET

26

08037-01008

GROMMET

27

08037-01610

GROMMET

28

09415-01008

CAP

29

09415-00706

CAP

30

01220-40412

SCREW

31

01641-20405

WASHER

32

01220-40612

SCREW

33

01641-20608

WASHER

34

01370-00412

SCREW
