Запчасти Komatsu PC50UU-2 ОСНОВН. КЛАПАН (-КЛАПАН) (ДЛЯ КЛАПАН ЛЕВ.)(/)(НАКЛОНЯЕМ. МЕХАНИЧ. ANGLE/ НАВЕСН. ОБОРУД/ ТЕЛЕСКОПИЧЕСК. РУКОЯТЬ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$3

709-35-12300

VALVE ASS'Y

|$4

709-35-11700

VALVE ASS'Y

|$5

709-35-11500

VALVE ASS'Y

|$7

709-35-00080

BODY GROUP ASS'Y

|$8

709-35-00050

BODY GROUP ASS'Y

|$9

709-35-00030

BODY GROUP ASS'Y

|$10

709-35-10700

BODY SUB ASS'Y

|$11

709-35-10300

BODY SUB ASS'Y

1

BLOCK

2

BLOCK

3

BLOCK

3

BLOCK

4

BLOCK

4

BLOCK

5

COVER

6

07000-12055

O-RING

7

709-35-11510

STUD

8

01580-10806

NUT

9

SPOOL

10

SPOOL

11

SPOOL

11

SPOOL

12

709-32-11530

SEAL

13

709-32-11540

PLATE

14

01252-60610

BOLT

14

01252-30610

BOLT

15

709-32-11550

RETAINER

16

709-32-11560

COLLAR

17

709-32-11580

SPRING

18

01252-60620

BOLT

18

01252-30620

BOLT

19

709-32-11570

COVER

20

01252-60616

BOLT

20

01252-30616

BOLT

21

04260-01270

BALL

22

709-32-11820

SPRING

23

709-32-11810

PLUG

24

07002-11823

O-RING

25

709-32-11930

PLUG

26

709-32-11830

PLUG

27

709-32-11840

O-RING

28

07002-12034

O-RING

28

07002-02034

O-RING

29

SPOOL

29

SPOOL

30

SPOOL

30

SPOOL

31

709-32-12851

CASE

32

709-32-12840

RETAINER

33

709-32-13510

SPRING

33

709-32-13510

SPRING

34

709-32-14510

SPRING

34A

709-32-14830

COLLAR

35

709-32-11760

O-RING

36

01252-60622

BOLT

36

01252-30622

BOLT

37

01641-20608

WASHER

38

07040-11007

PLUG

39

07002-11023

O-RING

40

07040-11812

PLUG

41

07002-11823

O-RING

42

709-32-13830

SHIM
