Запчасти Komatsu PC50UU-2 КОНЕЧНАЯ ПЕРЕДАЧА (МОТОР ХОДА /) (КОНЕЧНАЯ ПЕРЕДАЧА)(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

20U-60-23331

MOTOR A.

|$3

20U-60-23330

TRAVEL MOTOR ASS'Y

|$5

TZ598B1000-00

FINAL ASS'Y

|$6

TZ587B1000-00

FINAL ASS'Y

|$7

TZ598B1102-00

SPINDLE KIT

|$8

TZ587B1102-00

SPINDLE KIT

1

TZ598B1132-00

SPINDLE ASS'Y

1

TZ587B1132-00

SPINDLE ASS'Y

1

TZMB700-060

PLUG

2

TZ550A1019-00

BOLT,REAMER

3

TZJW1516-G26-7

O-RING (K1)

4

TZ596B1001-00

HUB

4

TZ573B1001-00

HUB

5

TZES100-178-B

SEAL,FLOATING (K1)

6

TZ573B1021-00

BEARING,BALL

7

TZ573B1017-00

PIN

|$19

TZ573B1104-02

RV GEAR ASS'Y

8

TZ573B1204-02

RV GEAR KIT (2 PIS)

9

TZ510B1009-00

SHAFT,CRANK

10

TZ310B1022-01

BEARING,ROLLER

11

TZ850A1023-00

BEARING,ROLLER

12

TZ310B1013-00

SNAP RING KIT (12 KINDS)

13

TZ550B1014-00

PIECE,DISTANCE

13

TZ550A1014-00

PIECE,DISTANCE

|$27

TZ512B1107-00

SPUR GEAR KIT (3 PIS)

14

SPUR GEAR

15

04064-02212

RING,SNAP

16

TZ512B1006-01

GEAR,INPUT

16

TZ512B1006-00

GEAR,INPUT

17

04064-01510

RING,SNAP

18

TZ510B1008-01

COVER

18

TZ510B1008-00

COVER

19

07000-05200

O-RING (K1)

19

07000-15200

O-RING (K1)

20

TZ550A1018-00

RING

21

TZGM3-8

PLUG

22

07000-11007

O-RING (K1)

K-1

TZ587B9000-00

SEAL KIT

|$42

TZ571B2039-01

O-RING

|$43

TZ571B2035-01

O-RING

|$44

TZ15Z-17-35-8

SEAL,OIL

|$45

TZJB2401-P22-9

O-RING

|$46

07000-12012

O-RING

|$47

07000-11007

O-RING

|$48

TZJW1516-G26-7

O-RING

|$49

TZES100-178-B

SEAL,FLOATING

|$50

07000-05200

O-RING

|$51

07000-15200

O-RING

|$52

07000-11007

O-RING
