Запчасти Komatsu PC50UU-2 МОТОР ПОВОРОТА (/)(№8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$3

708-7R-00053

MOTOR ASS'Y

|$4

708-7R-00052

MOTOR ASS'Y

|$5

708-7R-00050

MOTOR ASS'Y

|$10

708-7R-01032

MOTOR SUB ASS'Y

|$11

708-7R-01031

MOTOR SUB ASS'Y

|$12

708-7R-01030

MOTOR SUB ASS'Y

1

708-7R-11611

PLATE,SWASH

2

708-7R-11710

WASHER

3

708-7R-11720

FILTER

|$16

708-7R-04031

HOUSING SUB ASS'Y

|$17

708-7R-04030

HOUSING SUB ASS'Y

4

HOUSING

4

HOUSING

5

PLUG

6

708-7R-11220

PLUG

7

07002-11223

O-RING

8

708-7R-11210

VALVE

9

722-10-91130

SPRING

10

709-32-12861

PLUG

11

07002-11823

O-RING

|$27

708-7R-03020

VALVE SUB ASS'Y

12

708-7R-11230

VALVE

13

708-7R-11240

POPPET

14

708-7R-11250

PLUG

15

722-10-91130

SPRING

16

708-7R-11270

PLUG

17

07002-11823

O-RING

18

07000-02125

O-RING

19

720-68-19610

PIN

20

01252-61230

BOLT

21

708-7R-12111

SHAFT

22

708-7R-12140

BEARING

23

708-7R-12150

BEARING

24

04065-04218

RING

25

708-7R-13111

BLOCK,CYLINDER

26

708-7R-13220

PLATE,VALVE

27

720-68-19610

PIN

28

708-7R-13540

PIN

29

708-7R-13530

WASHER

30

708-7R-13560

SPRING

30

708-7R-13550

SPRING

31

04065-03012

RING

32

708-7R-13510

GUIDE,RETAINER

33

708-7R-13340

RETAINER,SHOE

34

708-7R-13310

PISTON SUB ASS'Y

35

708-7R-13410

PLATE,THRUST

36

708-7R-13581

SPACER

36

708-7R-13570

SPACER

37

708-7R-15130

PLATE

38

708-7R-15121

DISC

39

708-7R-15140

PISTON,BRAKE

40

07000-12110

O-RING

41

708-7R-15170

RING,BACK-UP

42

07000-12095

O-RING

43

07001-02095

RING,BACK-UP

44

708-7R-15150

SPRING

45

708-7R-15160

RING

46

708-7R-15712

PISTON

47

708-7R-15722

SPRING

|$66

708-7R-03010

VALVE SUB ASS'Y

48

VALVE

49

FILTER

50

708-7R-15670

SPRING

51

706-73-72680

PLUG

52

07002-11223

O-RING

53

07235-10422

ELBOW

54

07002-12034

O-RING

55

07221-20422

NUT,SLEEVE

56

07222-00414

PLUG
