Запчасти Komatsu PC50UU-2 ТОПЛИВН. БАК. (БАК) (EC СПЕЦ-Я.)(№8-799) ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

20U-04-21260

TANK

1

20U-04-21111

TANK

2

21Y-04-11381

FLANGE ASS'Y

2

21Y-04-11380

FLANGE ASS'Y

2

20U-04-21142

FLANGE

2

20U-04-21141

FLANGE

3

01220-40616

SCREW

3

01220-40630

SCREW

4

01602-20619

WASHER,SPRING

5

07000-02015

O-RING

6

20U-04-21150

FLANGE

7

01220-40620

SCREW

8

01602-20619

WASHER,SPRING

9

07000-02015

O-RING

10

20U-04-21160

FLANGE

11

20T-04-71120

VALVE

12

01220-40620

SCREW

13

01602-20619

WASHER,SPRING

14

07000-02015

O-RING

15

07270-00630

TUBE

16

07285-00068

CLIP

17

7861-92-5820

SENSOR,FUEL LEVEL

18

01252-40612

BOLT

19

01602-20619

WASHER,SPRING

20

07000-03048

O-RING

21

20U-04-21181

BRACKET

22

20U-04-21250

BRACKET

23

01010-51230

BOLT

24

01643-31232

WASHER

25

20U-04-21221

BAND

26

20U-04-21210

CUSHION

27

20U-04-21280

BAND

28

20U-04-21290

CUSHION

29

20U-04-21240

PIN

30

04052-11038

PIN,SNAP

31

01580-11210

NUT

32

01643-31232

WASHER

33

20U-04-21123

TUBE

33

20U-04-21122

TUBE

34

20M-04-71150

FILTER

35

20U-04-21360

CAP

36

07056-10045

STRAINER

37

01010-51020

BOLT

38

01643-31032

WASHER

39

20U-04-21131

HOSE

40

07281-00709

CLAMP

41

20U-04-21320

TUBE

42

07285-00155

CLIP

43

201-04-21160

BALL,FLOAT

44

20U-04-21370

JOINT

45

07288-01001

HOSE

46

07285-00150

CLIP

46

07281-00197

CLAMP
