Запчасти Komatsu PC50UD-2 КАБИНА (КОРПУС)(№8-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

Схема запчастей Komatsu PC50UD-2 - КАБИНА (КОРПУС)(№8-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
1
2
3
4
5
5
6
7
8
9
9
10
11
12
12
13
14
15
16
17
18
19
20
21
22
23
24
24
25
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43

Артикул

Название

Примечание

Количество

|1

20U-54-00059

CAB ASS'Y

|1

20U-54-00058

CAB ASS'Y

|1

20U-54-00057

CAB ASS'Y

|1

20U-54-00056

CAB ASS'Y

|1

20U-54-00078

CAB ASS'Y,(WITH FRONT GUARD)(FOR PC50UD)

|1

20U-54-00077

CAB ASS'Y,(WITH FRONT GUARD)(FOR PC50UD)

|1

20U-54-00076

CAB ASS'Y,(WITH FRONT GUARD)(FOR PC50UD)

|1

20U-54-00173

CAB ASS'Y,(WITH HEAD GUARD)

|1

20U-54-00172

CAB ASS'Y,(WITH HEAD GUARD)

|1

20U-54-00171

CAB ASS'Y,(WITH HEAD GUARD)

|1

20U-54-00170

CAB ASS'Y,(WITH HEAD GUARD)

1

20U-54-24671

BRACKET

2

01010-D0816

BOLT

3

01643-70823

WASHER

4

205-54-63311

LOCK ASS'Y

|4

205-54-63310

LOCK ASS'Y

5

01010-D0816

BOLT

5

01010-80816

BOLT

6

01643-70823

WASHER

7

20T-54-84620

STOPPER,L.H.

|7

20T-54-74311

STOPPER,L.H.

8

20T-54-84630

STOPPER,R.H.

|8

20T-54-74331

STOPPER,R.H.

9

20Y-54-14280

SCREW

10

205-54-71560

TRIM

11

20U-54-24652

SEAL

|11

20U-54-24651

SEAL,FRONT

12

01641-21016

WASHER

13

20U-54-24592

GLASS,FRONT¤ LOWER

14

22M-54-14560

LATCH,L.H.

|14

20U-54-24611

LATCH,L.H.

15

22M-54-14570

LATCH,L.H.

|15

20U-54-24621

LATCH,R.H.

16

20T-54-32780

PACKING

17

20T-54-32870

PACKING¤ 1.0MM

18

20T-54-32750

PACKING¤ 2.0MM

19

20T-54-32760

RETAINER,L.H.

20

20T-54-32770

RETAINER,R.H.

21

01023-20512

SCREW

22

01601-20513

WASHER

23

20U-54-24792

GLASS,REAR¤ UPPER

24

205-54-51720

RETAINER

25

205-54-51730

PACKING

26

01224-70610

SCREW

27

20U-54-25970

LOCK,QUARTER¤ L.H.

|27

20U-54-25980

LOCK,QUARTER¤ R.H.

|27

20U-54-25640

LOCK,QUARTER

28

01224-40510

SCREW

29

01584-00504

NUT

30

20U-54-24814

WIRING

|30

20U-54-24813

WIRING

|30

20U-54-24812

WIRING

31

21W-54-14691

CLIP

32

08059-00310

CLIP

|32

21W-54-14690

CLIP

33

20T-54-84610

PLATE

|33

20T-54-84610

PLATE

34

01370-40412

SCREW

35

205-54-51250

HANGER

36

01225-70412

SCREW

37

20U-54-25570

CAP

38

20U-54-25180

COVER

39

01220-70612

SCREW

40

01643-70623

WASHER

41

20U-54-24781

GUARD

42

01010-D0820

BOLT

43

01643-70823

WASHER

Выбрано товаров: 67
