Запчасти Komatsu PC50UD-2 КОНЕЧНАЯ ПЕРЕДАЧА (МОТОР ХОДА /) (КОНЕЧНАЯ ПЕРЕДАЧА)(№7-799) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20U-60-23320

TRAVEL MOTOR ASS'Y

|1

TZ535B1000-00

FINAL ASS'Y

|1

TZ535B1102-00

SPINDLE KIT

1

TZ535B1132-00

SPINDLE ASS'Y

|1

TZMB700-060

PLUG

2

TZ550A1019-00

BOLT,REAMER

3

TZJW1516-G26-9

O-RING (K1)

4

TZ510B1001-01

HUB

|5

TZ178-210-31

FLOATING SEAL KIT

5

TZES100-178-A

SEAL,FLOATING (K1)

6

TZ550A1010-01

PIECE,DISTANCE

7

07000-15210

O-RING (K1)

8

TZ510B1021-00

BEARING,BALL

9

TZ310B1017-00

PIN

|10

TZ510B1104-00

RV GEAR ASS'Y

10

TZ510B1204-00

RV GEAR KIT (2 PIS)

11

TZ510B1009-00

SHAFT,CRANK

12

TZ310B1022-01

BEARING,ROLLER

13

TZ850A1023-00

BEARING,ROLLER

14

TZ510B1011-00

RING

15

TZ310B1013-00

SNAP RING KIT (12 KINDS)

16

TZ550A1014-00

PIECE,DISTANCE

|17

TZ512B1107-00

SPUR GEAR KIT (3 PIS)

17

SPUR GEAR

18

04064-02212

RING,SNAP

19

TZ512B1006-01

GEAR,INPUT

20

04064-01510

RING,SNAP

21

TZ510B1008-01

COVER

22

07000-15200

O-RING (K1)

23

TZ550A1018-00

RING

24

TZGM3-8

PLUG

25

07000-11007

O-RING (K1)

K-1

TZ511B9000-01

SEAL KIT

|K

TZJB2401-P22-9

O-RING

|K

07000-12012

O-RING

|K

TZ15Z-17-35-8

SEAL,OIL

|K

TZJW1516-G26-9

O-RING

|K

TZES100-178-A

SEAL,FLOATING

|K

07000-15210

O-RING

|K

07000-15200

O-RING

|K

07000-11007

O-RING
