Запчасти Komatsu PC50UD-2 МОТОР ПОВОРОТА (/)(№7-799) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-7T-00180

MOTOR ASS'Y

|1

MOTOR SUB ASS'Y

1

708-7T-11240

CASE,MOTOR

2

07040-11409

PLUG

3

07002-01423

O-RING

4

708-7T-11650

COVER,END

5

706-73-72420

VALVE

6

706-73-72440

SPRING

7

706-73-72430

PLUG

8

07002-12434

O-RING

9

708-7T-51210

O-RING

10

720-68-19610

PIN

11

01010-81250

BOLT

12

708-7T-12310

SHAFT

13

708-7T-12240

BEARING

14

708-7T-12250

BEARING

15

708-7T-05020

SPACER KIT

|15

SPACER¤ 1.6MM

|15

SPACER¤ 1.7MM

|15

SPACER¤ 1.8MM

|15

SPACER¤ 1.9MM

|15

SPACER¤ 2.0MM

|15

SPACER¤ 2.1MM

|15

SPACER¤ 2.2MM

16

708-7T-12230

SEAL,OIL

17

04065-04518

RING,SNAP

18

708-7T-13140

BLOCK,CYLINDER

19

708-7T-13261

PLATE,VALVE

20

720-68-19610

PIN

21

708-7T-13540

PIN

22

708-7T-13530

WASHER

23

708-7T-13570

SPRING

24

04065-03815

RING,SNAP

25

708-7T-13510

GUIDE,RETAINER

26

708-7T-13342

RETAINER,SHOE

27

708-7T-13611

PISTON SUB ASS'Y

28

708-7T-13421

PLATE,THRUST

29

708-7T-13710

SPACER
